OLG-10LN Integration Type Screw Air Compressor

Send Inquiry to This Supplier

Mr. Steven Liu

Managing Director

Shenyang Acecare Technology Co., Ltd.

Shenyang, Liaoning, China

* Message

0/5000

* Email

Get quotes from multiple Verified Suppliers simultaneously.

NO.	project		unit	parameters
1	air displacement		(m³/min)/ MPa	1.2/0.7
				1.1/0.8
				1.0/1.0
				0.8/1.25
2	ambent temperature		°C	-5~+45
3	cooling model
4	exhuast air temperature		°C	≤ambient temperature +15
5	lubricant oil		L	7
6	driveing model			belt
7	volume adjustment model			ON-OFF automatic adjustment
8	gas oil content		ppm	≤3
9	noise		dB(A)	65±2
10	brand of lubricant oil			ORIENT oil
11	safety valve work pressure		MPa	specified work pressure x1.1
12	motor	power	KW/HP	7.5/10
		speed	rpm	2878
		drive model		directly
		voltage/rate	V/Hz	380/50
		levels of protection/insulaton rating		IP54,F stage
13	fan	power	kW	0.18
		voltage/rate	V/Hz	380/50
		speed	rpm	960
		fan power	m³/min	30
14	tank		L	320
15	size (L ×W ×H)		mm	1380×600×1660
16	net weight		kg	340
17	output interface		in	G3/4″
