Help CenterJig Separator for Sale /barite Jig Separator
Related Products
-
2013 New Jig Separator for SaleUS$ 5,000 - 500,000MOQ: 1 Set -
Jig Separator Machinery/separator MachineUS$ 2,000 - 8,000MOQ: 1 Set
-
Jig Separator ManufacturerUS$ 5,000 - 500,000MOQ: 1 Set
-
Mineral Benefication/washing Process/ Black Lead Spiral Classifier PriceUS$ 1,500 - 2,500MOQ: 1 Set
-
Copper Ore Flotation Machine/gold Ore Flotation Separator/copper Ore Processing PlantUS$ 1,500 - 2,500MOQ: 1 Set
Jig is a gravity separation device, it works by gravity separation, in accordance with the gangue mineral density difference of separation, widely used in sand gold, iron ore, manganese ore, tungsten ore, tin, tantalum and niobium Ore, fluorite ore, barite ore, celestite ore, diamond ore and other metal and non-metallic mineral dressing, ore dressing works well.
Parameters:
Model |
LTP-34/2 |
LTA-1010/2 |
LTC-69/2 |
2LTC-366/8T |
2LTC-6109/8T |
AM-30 |
||
Type |
Lateral-
drive
|
Down-
moving
|
Side-moving |
Side-moving |
Side-moving |
Side-
moving
|
||
Cross sectional |
rectangle |
rectangle |
rectangle |
Trapezoid |
Trapezoid |
|||
|
Jigging room
|
Size mm |
450x300 |
1000x1000 |
900x600 |
600x(300-600) |
900x(600-1000) |
||
Single room |
0.135 |
1.0 |
0.54 |
0.2-0.34 |
0.58-0.86 |
|||
Columen No. |
1 |
1 |
1 |
2 |
2 |
|||
Room No. |
2 |
2 |
2 |
8 |
8 |
|||
Total area |
0.27 |
2.0 |
1.08 |
2.16 |
5.76 |
|||
stroke coefficient |
0.58 |
0.5 |
0.56 |
0.68-0.41 |
0.52-0.35 |
0.47 |
||
|
Diaphragm
|
Stroke mm |
0-25 |
0-25 |
0-50 |
0-50 |
0-50 |
||
frequency of stroke |
320-420 |
250-350- |
220-350 |
120-300 |
120-300 |
|||
Max. feed size mm |
12 |
5 |
12 |
5 |
5 |
30 |
||
Capacity (t/h) |
2-6 |
5-15 |
6-9 |
3-6 |
10-20 |
10-15 |
||
Water consumption (t/h) |
4-10 |
10-20 |
40-60 |
20-40 |
80-120 |
|||
Motor |
Power (kw) |
1.1 |
2.2 |
1.5 |
1.1x2 |
2.2x2 |
3 |
|
...
Our Services
Pre-sale
1. Depending on customer's requirement, we insist on "making profit at lowest investment" and gives best solution as per the customer’s special demand.
2. Design the most reasonable project and maximum customers' profit.
3.Provide engineers to scene to plan work site if the customer needed.
4. Provide equipment list, design drawing, construction drawing, equipment install drawing.
During-sale
1. Depend on scene, draw design drawing , construction drawing, equipment install drawing, civil work detailed drawing for references, operating manuals, maintenance video, etc
2.Manufacturing products strictly on contract while customer constructing.
3. Production progress report each week with detailed description and photos, including raw materials tables, process and deep process record, testing data sheet, etc.
4. Testing all the equipments by witness of the customer ex-work, delivery, customer acceptance.
After-sale
1. Provide engineer to work site guiding install, debugging and commissioning.
2. Test equipment after installation, training operators for free, remind notice in operating.
3. Regularly returning visit to the customers.
4. Within warranted period, we take charge of everything if any quality problems. After the warranted period, we still focus on the plant running and services.
5. Response customer’s questions within 1 working day, give effective solutions within 3 working days, go into action with 5 working day.
That’s our promise, as we know quality and service both are important for long-term’s development and cooperation.
