SW460E EXCAVATOR
NO. |
DESCRIPTION |
SPECIFICATON |
|
||||
|
1 |
Main machine |
|
|
||||
(1) |
Working weight |
45500kg |
|
||||
(2) |
Bucket capacity |
2.1M3 |
|||||
(3) |
Track width |
600mm |
|||||
(4) |
Transport dimension |
12010*3490*3458mm |
|||||
(5) |
Overall dimension |
Length of track on ground |
4033mm |
||||
Length of track |
5051mm |
||||||
Ground clearance of counter weight |
1373mm |
||||||
Tail swing radius |
3600mm |
||||||
Track gauge |
2740mm |
||||||
Min. ground clearance |
725mm |
||||||
Track height |
1205mm |
||||||
Top width |
2995mm |
||||||
(6) |
Working range |
Max. working radius |
11945mm |
||||
Max. digging depth |
7490mm |
||||||
Max. digging height |
10960mm |
||||||
Max. vertical digging depth |
7040mm |
||||||
Max. dump height |
7700mm |
||||||
Min. swing radius |
4033mm |
||||||
(7) |
Performance |
Ground pressure |
85.9Kpa |
||||
Swing speed |
8.7r/min |
||||||
Travelling speed high/low |
5.0/3.0km/h |
||||||
Grade ability |
70° |
||||||
(5) |
Engine |
Company |
CUMMINS QSM11-335 |
||||
Type |
6 cylinder, inline, turbocharged and after-cooler |
||||||
Rated horsepower |
274KW/1800rpm. |
||||||
Send Inquiry to This Supplier
