Outdoor Water-proof SONY CCD 700TVL Analog Night-vision IR Camera Kit

Outdoor Water-proof SONY CCD 700TVL Analog Night-vision IR Camera Kit thumbnail-1
Outdoor Water-proof SONY CCD 700TVL Analog Night-vision IR Camera Kit thumbnail-2
Outdoor Water-proof SONY CCD 700TVL Analog Night-vision IR Camera Kit thumbnail-3
Outdoor Water-proof SONY CCD 700TVL Analog Night-vision IR Camera Kit thumbnail-4
Outdoor Water-proof SONY CCD 700TVL Analog Night-vision IR Camera Kit photo-1
Outdoor Water-proof SONY CCD 700TVL Analog Night-vision IR Camera Kit photo-2
Outdoor Water-proof SONY CCD 700TVL Analog Night-vision IR Camera Kit photo-3
Outdoor Water-proof SONY CCD 700TVL Analog Night-vision IR Camera Kit photo-4
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
HOCA
Place of Origin:
China
Model Number:
DLX-AK7
Contact Supplier Request Quote Chat Now
Shenzhen Hongcai Security&Safety Limited Company
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
5 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name HOCA
Place of Origin China
Model Number DLX-AK7
Type Analog Camera
Special Features Waterproof / Weatherproof
Technology Infrared
Sensor CCD
Style Bullet Camera

Brief introduction

     DLX-AK  4ch/8ch/16ch Analog CCD/CMOS camera kit is including 4/8/16pieces  analog CCD/CMOS camera, one 4ch/8ch/16ch DVR and other accessories (like  power adapter,cable,screws etc.).it support remote view by mobile, PC  etc. Support P2P,Cloud/USB/HD record and replay etc.

Features:

◊ Adopts original SONY CCD chip or Micron CMOS chip, lossless image

◊ 4/8/16channels optional, Outdoor weather-proof bullet camera/Indoor dome  camera optional

◊ Min.  Illumination: 0LUX(IR  ON)

◊    Built-in double IR-CUT filter (only for CMOS chip), No color deviation

◊  Adopts Long-life and SMART φ5 IR Leds or Epistar IR Arrays

◊ 3.6mm/4mm high quality  lens, 6mm,8mm,12mm,16mm optional(3.6mm for normal lens,4mm for big lens)

◊  Adopts double glass, the image more clear and bright

◊  Support  Auto, manual, moving Detection, alarm etc. record

◊  Support P2P, Cloud/USB/HD record, reply etc.

◊  Support 1/4/8/9/16images display

◊  one VGA,one HDMI,one 10/100M RJ45 port

Specification:



DVR

Video input

4/8/16channels 960H

HDMI output

  1channel

VGA output

  1channel

Audio output

 4channel(4/8ch DVR), 2channel(16ch DVR)

Storage

 One   SATA(Max.4TB)

USB

 2 USB2.0

RS485

  1channel

Record/

Reply

 4/8/16channels

Internet port

 one 10/100M RJ45

Camera

Sensor

1/2.8" CMOS

1/3" CMOS

1/4" CMOS

1/3" CCD

Resolution

1200TVL

1080TVL

800TVL

700TVL

Signal system

PAL/NTSC

Lens

Fixed 3.6/4mm(6,8,12,16mm optional)

IR

φ5 IR Leds or Epistar IR Arrays,IR range 30M to 80M optional

BLC/AGC

Auto

Electronic shutter

1/50(1/60)s to  1/100,000s

S/N

>52dB

Gamma correction

>0.45

Video output

1.0Vp- p75Ω（BNC)

Power

DC12V ±10%

Product Tags: CCTV Camera Kit , CCD camera Kit , SONY CCD 700TVL camera DVR kit
