Industrial High Temperature Precision Hot Air Cycle Drying Test Oven
US$ 1500 - 3000
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Yuanyao
Place of Origin:
China
Model Number:
YOT-080
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
20 days
Related Products
-
IP Grade Dust and Sand Proof Experimental Test InstrumentsUS$ 1500 - 3000MOQ: 1 Piece -
Industrial Hot Air Circle Oven for Materials Test EquipmentUS$ 1600 - 10000MOQ: 1 Piece
-
Precision Hot Air Oven 300 Degree Heating Drying Test Equipment MachineUS$ 1600 - 10000MOQ: 1 Piece
-
480L Industrial Precision Hot Air Drying Oven EquipmentUS$ 1600 - 10000MOQ: 1 Piece
-
High Temperature Endurance Ageing Industrial Test OvenUS$ 1600 - 10000MOQ: 1 Piece
Brand Name
Yuanyao
Place of Origin
China
Model Number
YOT-080
Type
Control Box
External Size
1900*1400*1300
Protection Level
Other
Industrial High Temperature Precision Hot Air Cycle Drying Test Oven
Brief Introduction & Main application:
Industrial High Temperature Precision Hot Air Cycle Drying Test Oven is widely used to test materials resistance performance in high temperature test condition. It is widely applied to Circuit boards, electronic component, photoelectric device, electroplating metal, plastic chemical industry, printing industry, processing coating, ceramic glass and transformer, inductance coil, motor coil baking, drying, aging, etc.
Main Features:
1. Microcomputer electronic digital control, precision & reliability.
2. High temperature endurance & non-aging.
3. Observation view window, easy operation.
4. Forced circulation air, the temperature rise fast, even distribution.
5. PID control, double overheating protection, safety and reliability.
6. Two groups of moving plates can be adjusted height. 9 Best after sales service: One year free parts warranty service.
7. Meet international test standards.
8. Customization is available & welcomed.
Industrial High Temperature Precision Hot Air Cycle Drying Test Oven is widely used to test materials resistance performance in high temperature test condition. It is widely applied to Circuit boards, electronic component, photoelectric device, electroplating metal, plastic chemical industry, printing industry, processing coating, ceramic glass and transformer, inductance coil, motor coil baking, drying, aging, etc.
Main Features:
1. Microcomputer electronic digital control, precision & reliability.
2. High temperature endurance & non-aging.
3. Observation view window, easy operation.
4. Forced circulation air, the temperature rise fast, even distribution.
5. PID control, double overheating protection, safety and reliability.
6. Two groups of moving plates can be adjusted height. 9 Best after sales service: One year free parts warranty service.
7. Meet international test standards.
8. Customization is available & welcomed.
Technical parameters:
| Model | YPO-072 | YPO-270 | YPO-480 | YPO-600 | YPO-720 | YPO-1000 |
| Inner chamber size W×H×D(cm) | 40×45×40 | 60×90×50 | 80×100×60 | 100×100×60 | 100×120×60 | 100×100×100 |
| External chamber size W×H×D(cm) | 72×116×56 | 93×163×67 | 110×172×77 | 130×172×77 | 116×170×116 | 116×150×166 |
| Temperature range | Room temperature+25ºC~200ºC(300ºC) | |||||
| Temperature fluctuation | ±0.3ºC | |||||
| Temperature uniformity | ±1%ºC | |||||
| Temperature resolution | 0.1ºC | |||||
| Heating up time | 30min | |||||
| External chamber material | Cold roolled sheet + Powder coating | |||||
| Internal chamber material | SUS#201 stainless steel plate (Adopt SUS#304 stainless steel when temperature>200ºC) | |||||
| Insulation | Fiberglass wool | |||||
| Wind circulation system | Centrifugal fan air circulation system | |||||
| Heating system | SUS#stainless steel high-speed heater | |||||
| Control system | Button type Digital controller | |||||
| Other components | Cotrol status indicator,loading shelf(2pcs,height adjustable) | |||||
| Safety device | Phase sequence protection,overtemperature,overcurrent,overload protection | |||||
| Power supply | AC 1ψ220V 60/50Hz;AC 3ψ380V 60/50Hz | |||||
| Customization service | Non-standard or special requirements are all welcome | |||||
