CK45 Slant Bed CNC Lathe Machine
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CAK6161X750 High Precision and Cheap Price Horizontal CNC Lathe Machine SpecificationNegotiableMOQ: 1 -
SK50P 500mm Mini Lathe Cnc for Metal WorkNegotiableMOQ: 1
-
CK0640 High Precision Benchtop Cnc Lathe With Pneumatic ChuckNegotiableMOQ: 1
-
CK0640 High Precision Benchtop CNC Lathe for Metal WorkingNegotiableMOQ: 1
-
CK6432 Mini China Cnc Lathe Machine for Metal WorkNegotiableMOQ: 1
Product Description
Product Application
We are manufacturer of CNC lathe.Slant bed horizontal CNC lathe,other full automatic CNC lathe.We also design and provide the one stop production solution for the customers
Specification |
CK45 |
Maximum swing dia.(mm) |
Φ450 |
Maximum cutting dia. (shaft / disk) (mm) |
Φ150 / Φ250 |
Maximum cutting length (mm) |
450 |
Chuck size (inch) |
8 |
Spindle type |
A2-6 |
Spindle bore through the rod (mm) |
Φ52 |
Tailstock stroke(mm) |
no tailstock |
Spindle speed (rpm) |
3500 |
Fast traverse speed (m / min) |
15/18 (x / z) |
X axis Travel(mm) |
900 |
Z-axis Travel (mm) |
600 |
Number of stations |
Gangtool/8 |
Time of tool exchange /s |
Gangtool/0.3 |
Cylindrical tool arbor size (mm) |
25 × 25 |
Spindle motor power KW (continuous / 30min continuous) |
7.5 / 11 |
Servo motor torque X / Z Nm |
15/15 |
Machine weight (kg) |
3500 |
