Hot Sale Bench Lathe Machine Metal Lathe Mini CJM360 Metal Lathe With CE
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
C6241x2000 mm Metal Manual Heavy Duty Lathe MachineNegotiableMOQ: 1 -
CW61125Q High Quality Heavy Duty Engine MachineNegotiableMOQ: 1
-
CJM320C High Quality Bench MachineNegotiableMOQ: 1
-
D250V With High Quality Beach Lathe MachineNegotiableMOQ: 1
-
DIY0714 High Quality Bench Lathe Machine Small Lathe for DIY and School TrainingNegotiableMOQ: 1
Product Description
Bench Metal Lathe Machine CJM360 For Processing Metal Machinery
1. Precision ground and hardened bed ways.
2. The spindle is supported with precision roller bearings.
3. Headstock gears are made of high quality steel, ground and hardened.
4. Easy operating speed change levers.
5. Spindle speed range 60-1600rpm.
6. Two different lengths of bed are available.
7. With or without cabinet according to requirement.
Specification |
CJM360 |
Max. swing diameter over bed |
360mm |
Max. length of work piece |
750mm/500 |
Max. swing diameter over middle carriage |
200 mm |
Spindle bore |
40mm |
Taper of hole in spindle |
MT5 |
Max. cross stroke over tool carrier |
160mm |
Max. longitudinal stroke over tool carrier |
100mm |
Metric thread kinds |
22 |
Metric thread pitch |
0.20-7mm |
Inch thread kinds |
45 |
Inch thread pitch |
21/2-48 1/n″ |
Modulus thread kinds on processing |
21 |
Modulus thread pitch on processing |
0.20-3.5mm |
Diametrical thread kinds on processing |
31 |
Diametrical thread pitch on processing |
8-120 1/n″ |
Longitudinal feed on spindle tool carrier |
0.10-1.40mm/r |
Cross feed on spindle tool carrier |
0.045-0.60mm/r |
Max stroke on taper hole |
80mm |
Taper of Tailstock |
MT3 |
Step of spindle speed |
12 |
Range of spindle speed |
60-1600r/mim |
N.W. |
420kgs |
G.W. |
470kgs |
Overall size(L×W×H) |
1580×785×1390mm |
Packing size(L×W×H) |
1600×800×1500mm |
Standard Accessories:
· 3-jaw chuck,
· Dead center
· Chasing dial indicator
· Change gears set
· Splash guard
· Oil gun
· Tool box and tools
Optional Accessories:
· 4-jaw chuck
· Machine stand
· Face plate
· Steady rest
· Follow rest
· Live center· Toolpost cover
· Chuck guard
· Leadscrew guard
Detailed Images
Company Profile
FAQ
Q1: How is the warranty?
A1: Warranty time is 13 months after BL date.
Q2:Can we visit your factory before order?
A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3:Do you have a stock?
A3:Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4:What’s the MOQ?
A4:One set only.
Q5:How about your quality?
A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6:Do you have professional engineers?
A6:Yes.we have professional engineers and designers. We can provide OEM services.
Q7:Can you provide customized machines?
A7:Yes, we can design and manufacture according to your specific requirements.
