The MVME3100 is a high-performance VME bus single-board computer launched by General Electric (GE), specifically designed for harsh industrial environments. Here are its detailed specifications:
Core Parameters

  • Processor: PowerPC 750CXe processor with a 500MHz clock speed, supporting 64-bit data processing and featuring an enhanced Floating-Point Unit (FPU). It can efficiently handle complex algorithms and real-time control tasks.

  • Memory Configuration:

    • 1GB DDR2 SDRAM (expandable to 2GB) with Error-Checking and Correction (ECC) functionality, ensuring the reliability of data transmission and storage.

    • 64MB Flash memory (expandable to 128MB) for storing operating systems, application programs, and configuration files.

  • Data Storage: Integrates a CFast slot that supports storage capacities of up to 32GB, providing high-speed data storage and system image backup capabilities.

Interface Specifications

  • VME Bus: Supports the VME64x standard (VITA 1-2001) with a 64-bit data bus and a maximum transfer rate of 80MB/s. It enables D0-D63 data transmission and supports advanced interrupt handling and arbitration mechanisms.

  • Communication Ports:

    • 3 RS-232/422/485 serial ports (DB9 connectors) with a maximum communication rate of 921.6kbps, configurable for industrial protocols such as Modbus RTU.

    • 2 Gigabit Ethernet ports (RJ45) that support TCP/IP, UDP, and IEEE 1588 Precision Time Protocol (PTP), suitable for high-speed data transmission and synchronous control.

    • 2 USB 2.0 ports (Type A) for high-speed peripheral connections (e.g., keyboards, mice, USB storage devices).

    • 1 VGA interface supporting display output at a maximum resolution of 1280×1024, used for local monitoring or debugging.


微信图片_20230421091302



  • Timing Functions:

    • A high-precision Real-Time Clock (RTC) with a backup battery (supporting approximately 5 years of standby time) to ensure accurate system time.

    • Programmable timers/counters that support PWM output, event counting, frequency measurement, and other functions.

Operating System Support

  • Real-Time Operating Systems (RTOS): Compatible with mainstream RTOS such as VxWorks, QNX, and Linux (including Wind River Linux and Red Hat Enterprise Linux), meeting real-time requirements in different industrial scenarios.

  • Development Environments: Works with development tools like Wind River Workbench and Eclipse, supporting programming languages such as C, C++, Ada, and Java.

Mechanical and Environmental Parameters

  • Dimensions: Standard 6U VME board (160mm × 233.35mm), compliant with the VITA 3-1997 mechanical specification, supporting horizontal or vertical installation.

  • Cooling Method: Fanless design using large-area aluminum heat sinks and conduction cooling technology, adapting to high-vibration and dusty environments.


微信图片_202306161506412
