The MVME2301 is a VMEbus processor module launched by Motorola, belonging to the MVME2300 series. Here are its detailed specifications:
Processor

  • Adopts a 200MHz MPC603 processor, which is a 32-bit microprocessor from the MPC60x series, providing stable computing performance for embedded control tasks.

Memory & Storage

  • DRAM: Equipped with 16MB ECC (Error-Correcting Code) DRAM, ensuring the accuracy of data storage and transmission by detecting and correcting common internal data errors.

  • Flash Memory: Features 5MB flash memory, dedicated to storing system programs, boot code, and critical data, enabling stable startup and data persistence even after power loss.

Expansion Slots

  • 2 x 32/64-bit PMC (PCI Mezzanine Card) expansion slots with front-panel and P2 I/O interfaces, supporting the addition of functional modules such as I/O cards, communication adapters, or data acquisition cards.

  • 1 x 64-bit PCI expansion mezzanine connector, further enhancing expandability for customizing system functions based on application needs.

MVME2604-712—03



Interfaces

  • 1 x asynchronous serial debug port, used for system debugging, firmware updates, and command input during development or maintenance.

  • 1 x 10/100Mb/s Ethernet transceiver interface, supporting high-speed network communication and integration into industrial Ethernet systems for data transmission and remote monitoring.

Timers

  • Integrates 4 x 32-bit timers, 1 x 16-bit timer, and 1 x watchdog timer. These timers can be used for timing control, event counting, pulse width modulation (PWM), and system fault detection (the watchdog timer triggers a reset if the system malfunctions, ensuring operational reliability).

Mechanical & Additional Features

  • Flame Retardancy: Complies with the 94V-0 flame retardant rating, enhancing safety in environments with potential fire risks.

  • Front Panel: Conforms to the IEEE 1101 standard, with injection/ejection handles for easy installation and removal in rack-mounted systems, reducing maintenance time.

Model Variants
Some common variants include 1-W3345F01C, 1-W3345F01E, and 01-W3345F01H (specific configurations may vary slightly by variant, such as minor adjustments in I/O allocation or component ratings).
