Help CenterABB EI802F 3BDH000016R1 – Ethernet Interface Module for AC 800F / Freelance Controller Networks
Related Products
-
ABB EI801F (3BDH000015R1) – Ethernet Interface Module for AC 800F / Freelance SystemsUS$ 1360.00MOQ: 1 Combo -
ABB EI811F (3BDH000020R1) – Ethernet Interface Module for ABB Freelance/AC 800F Control NetworksUS$ 1360.00MOQ: 1 Combo
-
ABB FC95-22 (HESG440295R2 / HESG448688R22) – Procontrol P14 Control Module for Reliable DCS OperationUS$ 1360.00MOQ: 1 Combo
-
ABB EI812F (3BDH000021R1) – Ethernet Interface Module for Freelance AC 800F Control SystemsUS$ 1360.00MOQ: 1 Combo
-
ABB EST125-975 + DCC2382A – Motor Feedback and Control Interface for ABB Drive SystemsUS$ 2360.00MOQ: 1 Combo
Warranty: 365 days
Delivery: 1 week for in-stock; no more than one month at the latest
Payment: 50% advance payment, full payment for delivery
Express: FedEx, UPS, DHL
Designed for ABB AC 800F (Freelance) – Plug-in module that expands Ethernet networking on the controller.
10/100Base‑T Ethernet – RJ45 ports support typical 10/100 Mbps operation for plant and control networks.
Backplane powered – No external power wiring; simplifies cabinet layout and reduces wiring errors.
Status LEDs – Link/activity indicators help technicians verify connectivity at a glance.
Engineering and HMI connectivity – Typically used for controller configuration, service access, and operator station communication.
Industrial reliability – Built for continuous operation in control cabinets; stable behavior in most brownfield upgrades.
| Brand / Model | ABB EI802F (3BDH000016R1) |
| System Family | AC 800F / Freelance (800xA compatible environments) |
| HS Code | 8538.90 (Parts suitable for use with apparatus of 8537) |
| Function | Ethernet interface module for controller networking and station connectivity |
| Power Requirements | Supplied via AC 800F backplane (no external power feed) |
| Signal I/O Types | Ethernet only (no discrete/analog field I/O) |
| Communication Interfaces | 10/100Base‑T, RJ45; TCP/IP; auto‑negotiation in most cases |
| Installation Method | Plug-in module on AC 800F base; cabinet/DIN-rail mounted system |
EI802F is typically used wherever AC 800F controllers need reliable Ethernet connectivity:
Chemicals and specialty chemicals – linking controllers with operator stations and historian nodes.
Oil & gas (onshore plants, terminals) – segregated control/HMI networks with managed switching.
Power generation and utilities – engineering access and redundant controller communications.
Water & wastewater – SCADA integration over TCP/IP with simple diagnostics at the cabinet door.
Pharma and food – stable Ethernet layer for batch execution and recipe download (GMP environments).
Reliability – Purpose‑built by ABB for AC 800F, so firmware and diagnostics behave as expected in most cases.
Compatibility – Works within Freelance/800xA architectures; ideal for brownfield expansions and spares.
Lifecycle support – Simplifies maintenance planning; your team already knows ABB’s tooling and workflow.
Lower integration effort – Backplane power and native diagnostics reduce cabinet wiring and commissioning time.
Commercial assurance – 365‑day warranty and predictable lead time minimize downtime risk.
Cabinet environment – Mount in an enclosed control cabinet with adequate ventilation. Keep away from heat sources and high‑EMI equipment.
Backplane & grounding – Seat the module firmly on the AC 800F base; ensure cabinet and backplane grounding are intact to reduce noise.
Cabling – Use industrial Cat5e/Cat6 patch cords; avoid tight bends and route away from power cables. Shielded cables are recommended in noisy areas.
Network design – Assign static IPs per site standard or use managed switches with VLANs. Redundancy can be implemented at the network/switch level as required.
Safety – Observe ESD precautions. De‑energize the system before insertion/removal to avoid controller disruptions.
Routine checks – Periodically inspect connectors and LEDs, clean dust with dry air, verify link speeds, and keep controller firmware and engineering tools aligned per ABB guidance.
Manufacturer quality system: ISO 9001
Typical compliance: CE; RoHS; UL (varies by configuration and market)
Warranty: 365 days (provided by us)
PM802F – AC 800F CPU module
PS800 – Power supply for the AC 800F base
CI801 / CI modules – Fieldbus interfaces (e.g., PROFIBUS) for S800 I/O integration
S800 I/O series – Remote I/O modules when field signals are required
You might notice that EI802F keeps the networking side simple: plug in, set addressing, verify LEDs, and you’re ready. If you share your target firmware and network topology, we can double‑check compatibility before shipping so your team doesn’t lose time during the next maintenance window.
