As a leading manufacturer from Qingdao Conqinphi Environmental Technology Group Co., Ltd., we are proud to present our 260KLD Triple-effect Plate Evaporator, constructed from premium 304 Stainless Steel. This high-efficiency evaporation system is designed for demanding industrial applications, offering superior heat transfer, energy savings, and reliable performance. With a daily capacity of 260,000 liters and a robust triple-effect design, it is ideal for concentration processes in food processing, pharmaceutical manufacturing, chemical production, and wastewater treatment. Backed by our 1-Year Warranty and supported by a factory spanning 10,000–30,000 square meters with over 200 skilled employees, this evaporator delivers unmatched value and dependability.
Our team has been dedicated to environmental technology since 2015, and we have exported to markets across North America, South America, Europe, Asia, Africa, and Oceania. Every unit is built with precision engineering to meet the highest standards of hygiene and durability. The 304 stainless steel construction ensures corrosion resistance, easy cleaning, and long service life even under harsh operating conditions.
This plate evaporator uses a triple-effect arrangement to maximize steam economy, significantly reducing energy consumption compared to single-effect systems. The plate design provides large heat transfer surface area in a compact footprint, making it suitable for facilities with limited space. Below we outline the key features and technical specifications.
Key Features & Advantages
- Triple-effect design: Achieves high steam economy (approximately 3:1 ratio), reducing operating costs.
- 304 Stainless Steel construction: All wetted parts are made of 304 SS, ensuring food-grade hygiene and resistance to corrosion.
- Plate-type heat exchanger: Easy to clean, inspect, and maintain; high heat transfer coefficient for efficient evaporation.
- Capacity: 260KLD (260,000 liters per day): Suitable for medium to large-scale production lines.
- 1-Year Warranty Included: Covers manufacturing defects and gives you peace of mind.
- Compact and modular: Saves floor space and allows for future expansion or customization.
- Automated control system: Optional PLC control with touch screen interface for real-time monitoring.
- Energy-saving: Lower steam consumption per ton of water evaporated compared to falling film or forced circulation evaporators.
Technical Specifications
| Parameter | Value |
|---|---|
| Model | 260KLD Triple-effect Plate Evaporator |
| Evaporation Capacity | 260,000 L/day (10,800 L/h approx.) |
| Number of Effects | 3 |
| Material of Construction | 304 Stainless Steel (AISI 304) |
| Heat Exchanger Type | Plate type (gasketed or welded, customizable) |
| Warranty | 1 Year (included) |
| Operating Pressure | Atmospheric to vacuum (optional) |
| Power Supply | 380V/50Hz (customizable upon request) |
| Control System | Optional PLC + HMI touch screen |
| Applications | Milk, juice, sugar solutions, pharmaceutical extracts, chemical solutions, wastewater |
The triple-effect plate evaporator is engineered to minimize scaling and fouling, with easy access for cleaning. The plates are designed with optimal flow channels to handle viscous products and reduce product degradation. Our customers benefit from lower energy bills, reduced downtime, and consistent product quality.
Why Choose Us?
- Manufacturer direct: We are a factory with 10,000–30,000 sqm manufacturing base, ensuring competitive pricing and quality control.
- Experienced team: Over 200 employees, including R&D engineers who can customize the evaporator to your specific process.
- Global reach: Annual export value of US$10M–US$50M, serving markets in North America, Europe, Asia, Africa, and Oceania.
- Certifications: Our factory is certified under ISO9001, ISO14000, OHSAS18001, HACCP, and other management systems (details available upon request).
- Proven track record: Since 2015, we have delivered hundreds of evaporation systems worldwide.
Our 260KLD Triple-effect Plate Evaporator comes with a standard 1-Year Warranty covering parts and workmanship. We also provide after-sales technical support, spare parts supply, and optional on-site installation guidance. Whether you need to concentrate dairy products, recover solvents, or treat industrial wastewater, this evaporator is a reliable solution.
Contact us today for a quotation or technical discussion. We can customize the evaporator with different plate materials, gasket materials, and control options to match your exact requirements. Choose Qingdao Conqinphi for quality, performance, and peace of mind.
Frequently Asked Questions (FAQ)
Q1: What is the typical steam consumption of this triple-effect evaporator?
A: In triple-effect mode, the steam economy is approximately 3:1, meaning you need about 0.33 kg of steam per kg of water evaporated. Actual consumption depends on product characteristics and operating parameters.
Q2: Can this evaporator handle viscous liquids like fruit juice concentrate?
A: Yes, the plate design with optimized flow channels can handle moderate viscosities. For highly viscous products, we can modify the plate configuration or recommend a forced circulation option.
Q3: Is the 304 stainless steel suitable for dairy applications?
A: Absolutely. 304 SS is food-grade and widely used in dairy and beverage industries. It meets HACCP and other hygiene standards. If you require higher corrosion resistance for acidic products, 316L is also available as an option.
Q4: What is the delivery time for this evaporator?
A: Standard delivery time is 45–60 days after order confirmation, depending on customization requirements. We can provide a precise schedule upon inquiry.
Q5: Does the 1-year warranty cover labor costs?
A: Yes, the warranty covers both parts and labor for defects arising from normal use under specified conditions. Consumables (gaskets, seals) are covered for 6 months. Please refer to our warranty policy for full details.
Q6: Can I get a custom capacity other than 260KLD?
A: Yes, we offer a range of models from 10KLD to 500KLD. Contact us with your required capacity and we will recommend the most suitable configuration.
Q7: How do I clean the plate heat exchanger?
A: The plates can be cleaned in place (CIP) using standard cleaning solutions. The gasketed design allows easy disassembly for manual cleaning when needed. We provide a cleaning manual with the unit.
Q8: What certifications does your factory hold?
A: Our factory is certified under ISO9001, ISO14000, OHSAS18001, and HACCP. We also comply with various international standards. Certificates are available upon request.
