Help CenterSemi-Welded Plate Heat Exchanger for Milk Processing, 20 Bar, 130°C, Sanitary Tri-Clamp Connections
Product Spotlights
Related Products
-
1 Year Warranty Fruit Juice Concentrate Plate Heat Exchanger, 4000–7000 W/(m²·K) With Mill Test ReportUS$ 2790 - 85780MOQ: 1 Combo -
Fruit Juice Concentrate Processing Plate Heat Exchanger, 4000–7000 W/(m²·K) for Beverage IndustryUS$ 2790 - 85780MOQ: 1 Combo
-
Automatic Cleaning CIP System Plate Heat Exchanger for Fruit Juice Concentrate, 4000–7000 W/(m²·K)US$ 2790 - 85780MOQ: 1 Combo
-
High Efficiency Pasteurization Plate Heat Exchanger for Fruit Juice Concentrate, 4000–7000 W/(m²·K)US$ 2790 - 85780MOQ: 1 Combo
-
304 Stainless Steel Plate Heat Exchanger for Fruit Juice Concentrate, 4000–7000 W/(m²·K) Thermal ConductivityUS$ 2790 - 85780MOQ: 1 Combo
As a leading manufacturer based in Qingdao, China, Qingdao Conqinphi Environmental Technology Group Co., Ltd. (established in 2015) specializes in high-performance heat exchange solutions. Our Semi-Welded Plate Heat Exchanger is specifically engineered for milk processing, combining robust construction with sanitary design. With a working pressure of 20 Bar and temperature tolerance up to 130°C, this unit delivers reliable performance in demanding dairy applications. The sanitary tri-clamp connections ensure quick, leak-free assembly and easy cleaning, meeting the strictest hygiene standards. Our factory, spanning 10,000–30,000 square meters, houses over 200 skilled employees and exports to major markets worldwide, including North America, Europe, and Oceania.
Key Features & Technical Specifications
- Fully Welded Channel Design – Eliminates gaskets in the milk channel, reducing contamination risk and maintenance needs.
- High Pressure & Temperature Capability – Rated for 20 Bar and 130°C, ideal for pasteurization, sterilization, and CIP processes.
- Sanitary Tri-Clamp Connections – Provide smooth, crevice-free surfaces for fast assembly and thorough cleaning.
- Corrosion-Resistant Materials – Standard 316L stainless steel plates with optional 304 for less aggressive media.
- Compact Footprint – Achieves high heat transfer efficiency in a space-saving design, reducing floor space requirements.
- Easy Maintenance – Semi-welded construction allows individual plate replacement without disturbing adjacent channels.
| Parameter | Value |
|---|---|
| Design Pressure (Milk Side) | 20 Bar |
| Design Temperature | 130°C |
| Connection Size | 1” to 4” Tri-Clamp (customizable) |
| Plate Material | SS316L (0.5–0.8 mm thickness) |
| Gasket Material (Service Side) | EPDM, NBR, or Viton (optional) |
| Maximum Flow Rate | Up to 150 m³/h (dependent on model) |
The semi-welded technology offers distinct advantages over traditional gasketed plate heat exchangers. By welding the plates in pairs, the milk channel is completely sealed, eliminating the risk of cross-contamination between milk and service fluid (e.g., hot water or steam). This design also withstands higher pressures and temperatures, making it suitable for continuous pasteurization at 72–85°C and flash sterilization at 130°C. The sanitary tri-clamp connections align with 3-A Sanitary Standards and are widely accepted in dairy plants for their ease of disassembly and cleaning-in-place (CIP) compatibility.
Our heat exchangers undergo rigorous quality control at every stage, from raw material inspection to final pressure testing. Each unit is hydrostatically tested at 1.3 times the design pressure to ensure leak-free operation. The company holds multiple certifications including HACCP, ISO9000, ISO14000, and OHSAS18001, reflecting our commitment to food safety, quality management, and environmental responsibility. With an annual export value exceeding US$10 million, we have supplied thousands of units to dairy processors across 50+ countries.
FAQ
-
Q: Can this heat exchanger be used for other dairy products like cream or yogurt?
A: Yes, it is suitable for various viscous dairy products. The smooth plate channels and tri-clamp connections allow easy cleaning between batches. -
Q: What is the typical lead time for a custom order?
A: Standard models ship within 2–3 weeks after order confirmation. Custom sizes or special materials may require 4–6 weeks. -
Q: How do I clean the semi-welded heat exchanger?
A: We recommend CIP (clean-in-place) with alkaline and acid solutions. The welded milk channel can be cleaned separately from the service side. -
Q: Is this unit compatible with existing tri-clamp piping systems?
A: Yes, the tri-clamp connections are standard 3A-compliant fittings (1.5” to 4”). Adapters are available if needed. -
Q: What is the maximum number of plates per unit?
A: Typically up to 200 plates, depending on frame size. Contact our engineering team for specific capacity requirements. -
Q: Do you provide installation and commissioning support?
A: Yes, we offer remote technical guidance and can arrange on-site supervision for large projects upon request. -
Q: Are replacement plates available for future maintenance?
A: Absolutely. We stock standard plate sizes and can produce custom profiles. Spare parts are available for the entire lifespan of the unit. -
Q: What certifications do you hold for food contact materials?
A: Our plates and gaskets comply with FDA and EU regulations. The company is HACCP and ISO9000 certified.
With over 9 years of manufacturing experience, a dedicated R&D team, and a global service network, Qingdao Conqinphi is your trusted partner for dairy heat transfer solutions. Our semi-welded plate heat exchanger combines hygiene, durability, and efficiency to meet the most demanding milk processing requirements. Contact us today for a customized quotation or technical consultation.
