As a leading manufacturer from Qingdao Conqinphi Environmental Technology Group Co., Ltd., we proudly present our 316L Stainless Steel Gasketed Plate Heat Exchanger — a premium solution designed for hygienic and high-temperature heat transfer applications. Engineered with food-grade materials and certified to HACCP standards, this heat exchanger is ideal for industries requiring strict sanitation, such as dairy, beverage, pharmaceutical, and food processing. With a maximum operating temperature of 150°C and a flexible heat transfer area ranging from 1.0 m² to 5.0 m², it offers precise thermal management for your process.
Our factory, spanning over 10,000 square meters with a skilled workforce of 200+, has been delivering reliable heat exchange equipment since 2015. We export to global markets including North America, Europe, and Southeast Asia, with annual export value exceeding US$10 million. This product embodies our commitment to quality, durability, and customer satisfaction.
Key Features & Technical Specifications
- Superior Material: All plates are made of 316L stainless steel, offering excellent corrosion resistance against chlorides, acids, and alkaline solutions — perfect for food-grade applications.
- High Temperature Capability: Designed to withstand continuous operation up to 150°C, suitable for pasteurization, sterilization, and other high-temperature processes.
- Gasketed Design: High-quality EPDM, NBR, or Viton gaskets (optional) ensure leak-free sealing and easy maintenance. Gaskets are replaceable, extending the equipment lifespan.
- Compact & Efficient: Plate geometry optimized for high turbulence and heat transfer coefficient, achieving up to 90% thermal efficiency. The compact footprint saves valuable floor space.
- Flexible Sizing: Available in heat transfer areas from 1.0 m² to 5.0 m², with customizable plate count and frame configuration to match your exact flow rates and temperature requirements.
- Food Grade Compliance: Manufactured in accordance with HACCP principles, with smooth surfaces and no dead zones to prevent bacterial growth. All wetted parts are 316L stainless steel and FDA-compliant gasket materials.
- Easy Maintenance: The plate pack can be easily opened for inspection, cleaning, or plate replacement. Gaskets are clip-on or glue-on design for quick replacement.
- Multiple Connection Options: Threaded or flanged connections available, with sizes ranging from DN25 to DN80. Custom connections upon request.
Technical Parameters (Typical Model)
| Heat Transfer Area | 1.0 - 5.0 m² (customizable) |
| Max Operating Temperature | 150°C |
| Max Operating Pressure | 1.0 MPa (10 bar) optional higher |
| Plate Material | 316L Stainless Steel (AISI 316L) |
| Gasket Material | EPDM (standard), NBR, Viton |
| Frame Material | Carbon steel with epoxy coating / 304 SS |
| Connection Size | DN25 – DN80 (1") – 3") |
| Applications | Dairy, beverages, juice, beer, edible oil, pharmaceutical, chemical, HVAC |
Benefits for Your Business
- Cost Savings: High thermal efficiency reduces energy consumption. Compact design lowers installation and piping costs.
- Product Quality: Precise temperature control protects sensitive products, preventing scorching or thermal degradation.
- Hygiene Assurance: Food-grade materials and HACCP-compliant design meet the strictest sanitary standards, reducing contamination risk.
- Long Service Life: 316L stainless steel resists pitting and crevice corrosion, even in CIP (clean-in-place) environments with aggressive chemicals.
- Versatility: Suitable for heating, cooling, pasteurization, and heat recovery across multiple industries.
Why Choose Qingdao Conqinphi?
With over 8 years of manufacturing experience, a factory of 10,000+ square meters, and a dedicated team of 200+ professionals, we specialize in producing high-quality heat exchangers for global clients. Our products are exported to North America, Europe, South America, Africa, and Oceania, with annual export value reaching US$10–50 million. We hold ISO9001 quality management system certification and HACCP certification for food safety, ensuring every unit meets international standards. Our port of shipment is Qingdao, providing convenient logistics to worldwide destinations.
We offer comprehensive after-sales support, including technical documentation, spare parts, and online troubleshooting. Customization is welcome — we can adjust plate count, frame size, connections, and gasket materials to fit your specific process. Contact us today for a quotation or technical consultation!
Frequently Asked Questions (FAQ)
-
Q: What is the maximum pressure this heat exchanger can handle?
A: The standard design pressure is 1.0 MPa (10 bar). Higher pressure ratings up to 1.6 MPa are available upon request with reinforced frames. -
Q: Can this heat exchanger be used for CIP (clean-in-place) cleaning?
A: Yes, the 316L stainless steel plates and gasket materials are compatible with common CIP chemicals (e.g., caustic soda, nitric acid). Please advise your cleaning agents so we can recommend suitable gasket material. -
Q: What gasket materials are available, and which one is best for food applications?
A: EPDM is standard for food contact (FDA approved). NBR is suitable for oils and fats, while Viton can handle higher temperatures and aggressive chemicals. We can advise based on your fluid. -
Q: Is the heat exchanger certified for food-grade use?
A: Yes, our manufacturing process follows HACCP guidelines, and we use FDA-approved materials. We can provide a certificate of compliance upon request. -
Q: What is the lead time for custom sizes?
A: Typically 15–25 working days for standard sizes, and 25–35 days for custom configurations, depending on order quantity. -
Q: Can I get a sample or small unit for testing?
A: Yes, we offer a 1.0 m² unit for pilot testing. Please contact our sales team for details. -
Q: How do I install and maintain the plate heat exchanger?
A: We provide installation manual and technical drawings. Regular inspection of gaskets and tightening of bolts is required. Our engineers can offer online guidance. -
Q: What is the warranty period?
A: We offer a standard 12-month warranty from the date of shipment, covering manufacturing defects. Extended warranty options are available.
Ready to upgrade your process? Contact us for a tailored solution that meets your exact heating and cooling needs.
