Qingdao Conqinphi Environmental Technology Group Co., Ltd. is a professional manufacturer of evaporation and crystallization equipment. Our Triple-effect evaporator crystallizer with a 2.2kW vacuum pump and PLC HMI touch screen is designed for efficient concentration and crystallization of liquid solutions. With a processing capacity of 600 L/h, this system combines advanced automation with robust construction to meet the demanding needs of industries such as wastewater treatment, chemical processing, and food production. The triple-effect design significantly reduces energy consumption compared to single-effect units, making it a cost-effective solution for your operation.
This evaporator crystallizer integrates a PLC-based control system with a user-friendly HMI touch screen, allowing operators to monitor and adjust parameters in real time. The vacuum pump ensures stable operation under low-temperature conditions, minimizing thermal degradation of heat-sensitive materials. The equipment is built with stainless steel (SS304 or SS316L) to resist corrosion and ensure long service life. Below are key technical specifications:
| Parameter | Value |
| Evaporation capacity | 600 L/h |
| Number of effects | 3 |
| Vacuum pump power | 2.2 kW |
| Working temperature | 50-90°C (adjustable) |
| Material | SS304 / SS316L (optional) |
| Control system | PLC + HMI touch screen |
| Power supply | 380V / 3-phase / 50Hz (or as required) |
Key features and benefits:
- Triple-effect design – Utilizes vapor from each effect to heat the next, reducing steam consumption by up to 60% compared to single-effect evaporators.
- PLC HMI touch screen – Intuitive interface for setting parameters, monitoring temperature, pressure, and flow, with alarm functions for safe operation.
- 2.2kW vacuum pump – Ensures stable vacuum levels (typically -0.08 to -0.095 MPa) for low-temperature evaporation, protecting heat-sensitive materials.
- High crystallization efficiency – Forced circulation or falling film design promotes uniform crystal growth, producing high-purity crystals.
- Corrosion-resistant construction – Stainless steel wetted parts and optional anti-corrosion lining for aggressive chemicals.
- Compact footprint – Skid-mounted design saves floor space and simplifies installation.
- Energy-saving – Lower energy consumption per ton of water evaporated, reducing operational costs.
Our factory, located in Qingdao, China, covers an area of 10,000-30,000 square meters and employs 201-300 skilled workers. With an annual export value of US$10-50 million and shipments to more than 10 global markets (including North America, Europe, Southeast Asia, Africa, and the Middle East), we have established a strong reputation for quality and reliability. Our company holds multiple certifications such as ISO9001, ISO14000, OHSAS18001, and HACCP, ensuring that every product meets rigorous standards. We have exported this triple-effect evaporator crystallizer to numerous clients in the chemical and wastewater industries, receiving positive feedback on performance and durability.
FAQs
-
Q: What types of liquids can this evaporator crystallizer process?
A: It is suitable for aqueous solutions, saline wastewater, chemical byproducts, and heat-sensitive materials. Custom materials (e.g., high-viscosity or corrosive liquids) can be handled with optional modifications. -
Q: How much energy is saved compared to a single-effect evaporator?
A: Typically, triple-effect systems save around 60% of steam consumption, as the vapor from each effect is reused. Exact savings depend on operating conditions. -
Q: Is the PLC HMI touch screen easy to operate?
A: Yes, the touch screen interface is designed with intuitive menus, real-time displays, and alarm logs. Operators can be trained within a few hours. -
Q: What is the typical maintenance requirement?
A: Regular inspection of seals, vacuum pump oil, and cleaning of heat exchanger surfaces is recommended. The PLC system has self-diagnostics to simplify maintenance. -
Q: Can the capacity be scaled up or down?
A: Yes, the 600 L/h model is a standard size. We can customize the design for capacities from 50 L/h to 20,000 L/h upon request. -
Q: What is the delivery time?
A: Standard models typically ship within 30-45 days after order confirmation. Customized units may require 60-90 days. -
Q: Do you provide after-sales service?
A: Yes, we offer online technical support, spare parts supply, and optional on-site installation guidance. Warranty is usually 12 months.
At Qingdao Conqinphi, we are committed to delivering high-quality evaporation and crystallization solutions. Our triple-effect evaporator crystallizer with PLC HMI touch screen and 2.2kW vacuum pump is a reliable choice for your process. Contact us today for a quotation or technical consultation – we look forward to partnering with you.
