Energy-Saving Flame Retardant Triple-Effect Evaporator, PLC Touch Screen, 10kW Power
Product Spotlights
This Energy-Saving Flame Retardant Triple-Effect Evaporator combines a 10kW power rating, PLC touch screen control, and three-effect heat recovery to reduce energy costs by up to 60%. Its flame retardant construction ensures safe operation, while the stainless steel build offers durability. Ideal for wastewater treatment and chemical concentration, backed by our ISO9001-certified manufacturing and global export experience.
US$ 52380 - 8639000
MOQ: 1 Combo
Key Specifications
Get Latest Price
Material:
Stainless Steel
Power:
10kW
Control System:
PLC Touch Screen
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
50 days
Related Products
-
Compact Large Triple-Effect Evaporator, PLC Control, 304 SS, 220V, 50HzUS$ 7380 - 574000MOQ: 1 Combo -
Industrial Large Triple-Effect Evaporator, 304 Stainless Steel, 380V, 2000L/HUS$ 7380 - 574000MOQ: 1 Combo
-
Large Triple-Effect Evaporator With Technical Training and Spare Parts, PLC Control, 304 SSUS$ 7380 - 574000MOQ: 1 Combo
-
Automatic Large Triple-Effect Evaporator, 304 SS, 220V, 2000L/H CapacityUS$ 7380 - 574000MOQ: 1 Combo
-
Large Triple-Effect Evaporator for Wastewater Treatment, Energy Saving, 304 SSUS$ 7380 - 574000MOQ: 1 Combo
Material
Stainless Steel
Power
10kW
Control System
PLC Touch Screen
Evaporation Type
Triple Effect
Flame Retardant
Yes
Application
Wastewater Treatment, Chemical Industry
Certification
HACCP, ISO9001, ISO14000
Voltage
380V / 440V (Customizable)
Dimensions (L×W×H)
Contact us for details
Weight
Contact us for details
Welcome to Qingdao Conqinphi Environmental Technology Group Co., Ltd., a professional manufacturer with over 8 years of experience in industrial evaporation solutions. Our Energy-Saving Flame Retardant Triple-Effect Evaporator with PLC Touch Screen integrates advanced three-effect evaporation technology, intelligent control, and enhanced safety features to deliver superior performance for liquid concentration and wastewater treatment. Designed to reduce energy consumption while ensuring operational safety, this evaporator is an ideal choice for industries seeking both efficiency and compliance.
Key Features & Technical Advantages
- Triple-Effect Evaporation Design: Utilizes three stages of heat recovery to maximize energy utilization. Compared to single-effect systems, it can reduce steam consumption by up to 60%, significantly lowering operating costs.
- Flame Retardant Construction: The unit is built with fire-resistant materials and components, meeting high safety standards for volatile or flammable processing environments. This feature minimizes fire risk and ensures workplace safety.
- PLC Touch Screen Control: Equipped with an intuitive HMI interface for real-time monitoring and parameter adjustment. Operators can easily set temperature, pressure, and flow rates, with automatic alarm and fault diagnosis functions.
- Energy-Saving Technology: The integrated heat exchanger and optimized vapor compression system achieve thermal efficiency above 90%. The 10kW power input supports continuous operation with minimal electricity consumption.
- Robust Stainless Steel Construction: Main body and piping are made of 304/316L stainless steel, offering excellent corrosion resistance and durability for long-term use in harsh chemical environments.
- Compact Footprint: The modular design saves floor space while maintaining high evaporation capacity. Suitable for both new installations and retrofit projects.
Technical Specifications
| Parameter | Value |
| Power Rating | 10 kW |
| Evaporation Capacity | 50–100 L/h (depending on feed concentration) |
| Number of Effects | 3 |
| Material of Construction | Stainless Steel 304/316L |
| Control System | PLC + 7-inch Touch Screen |
| Operating Temperature | 60°C – 100°C (adjustable) |
| Flame Retardant Rating | UL94 V-0 (key components) |
| Voltage / Frequency | 380V / 50Hz (440V / 60Hz optional) |
Customer Benefits
- Lower Operating Costs: The triple-effect design reduces steam usage by over 50% compared to single-effect evaporators, translating to significant savings on energy bills.
- Enhanced Safety: Flame retardant construction and built-in over-temperature protection ensure safe operation even when processing flammable solvents or high-temperature liquids.
- Easy Operation: The PLC touch screen provides a user-friendly interface with graphical displays, historical data logging, and remote monitoring capability (optional).
- High Reliability: All components are sourced from reputable suppliers, and the system undergoes rigorous factory testing (including pressure tests and performance validation) before shipment.
- Environmentally Friendly: By concentrating waste streams and recovering valuable byproducts, this evaporator helps reduce disposal volume and supports circular economy goals.
Company Strength & Trust
As a trusted manufacturer established in 2015, Qingdao Conqinphi Environmental Technology Group Co., Ltd. operates a factory of 10,000–30,000 square meters with 201–300 skilled employees. Our annual export value exceeds US$10 million, serving markets across North America, Europe, Southeast Asia, Africa, and Oceania. We hold multiple certifications including HACCP, ISO9001, ISO14000, OHSAS18001, and more, ensuring consistent quality and compliance with international standards. Our engineers provide comprehensive technical support, from process design to installation and after-sales service. Contact us today to discuss your specific evaporation requirements and receive a customized proposal.
Frequently Asked Questions
- Q1: What is the energy saving rate of this triple-effect evaporator?
- A: Compared to a single-effect evaporator, the triple-effect design can reduce steam consumption by approximately 50–60%. Actual savings depend on feed characteristics and operating conditions.
- Q2: Is the flame retardant feature suitable for flammable solvents?
- A: Yes. The unit is engineered with flame retardant materials and electrical components rated for hazardous environments. However, we recommend consulting our engineers for specific solvent compatibility to ensure safe operation.
- Q3: Can the PLC touch screen be integrated with existing SCADA systems?
- A: Yes, the PLC supports standard communication protocols such as Modbus RTU and TCP/IP, allowing integration with most SCADA or DCS systems. Remote monitoring is also available as an option.
- Q4: What is the typical evaporation capacity for a 10kW model?
- A: Under standard conditions (e.g., water evaporation at 100°C), the capacity ranges from 50 to 100 liters per hour. The exact value depends on the concentration and viscosity of the feed liquid.
- Q5: What certifications does this evaporator comply with?
- A: Our manufacturing facility is certified under ISO9001, ISO14000, and OHSAS18001. The evaporator itself can be designed to meet HACCP, CE, or other standards upon request. Please provide your target market for confirmation.
- Q6: How long is the warranty period, and what does it cover?
- A: We offer a standard 12-month warranty covering defects in materials and workmanship. Extended warranty options are available. Our after-sales team provides remote troubleshooting and spare parts support.
- Q7: What are the maintenance requirements for the evaporator?
- A: Routine maintenance includes cleaning the heat exchangers, checking seals, and calibrating sensors. The PLC system logs operating hours and alerts when maintenance is due. Detailed manuals are provided with each unit.
- Q8: Can I customize the evaporator for a specific application?
- A: Absolutely. We offer customization in terms of material grade, capacity, control options, and auxiliary equipment. Our engineering team will work with you to design a solution that fits your process requirements.
