Help CenterVacuum Wastewater Plate Evaporator, PLC Controlled, 1500L/H, 316L Stainless Steel for Fluorochemicals
Product Spotlights
Related Products
-
Wastewater Plate Evaporator for Lithium Battery Waste Treatment, Efficient Concentration of Heavy MetalsUS$ 8540 - 94600MOQ: 3 Combos -
Industrial Wastewater Plate Evaporator for Pharmaceutical and Pesticide Intermediates, Low Operating CostUS$ 8540 - 94600MOQ: 3 Combos
-
Automatic Wastewater Plate Evaporator, Complete Set, 380V, 5kW, for Rare Earth ExtractionUS$ 8540 - 94600MOQ: 3 Combos
-
Wastewater Plate Evaporator With 1 Year Warranty, Mill Test Report Provided, Easy MaintenanceUS$ 8540 - 94600MOQ: 3 Combos
-
Turnkey Wastewater Plate Evaporator Solution, Including Installation Training and Free Technical SupportUS$ 8540 - 94600MOQ: 3 Combos
Qingdao Conqinphi Environmental Technology Group Co., Ltd., established in 2015 with a factory area of 10,000-30,000 square meters and over 200 skilled employees, proudly presents our Vacuum Wastewater Plate Evaporator – a high-performance solution designed specifically for the demanding fluorochemical industry. This PLC-controlled system processes up to 1,500 liters per hour and is constructed entirely from durable 316L stainless steel, ensuring long-term corrosion resistance and reliability. Our evaporator combines advanced vacuum technology with precise automation, offering a cost-effective and energy-efficient way to treat challenging wastewater streams.
The core advantage of this equipment lies in its ability to handle high-concentration fluorochemical effluents under reduced pressure, which significantly lowers the boiling point and reduces energy consumption. The integrated PLC control system provides real-time monitoring and adjustment, enabling unattended operation and consistent output quality. Whether you need to concentrate, recover valuable chemicals, or minimize waste volume, this evaporator delivers dependable performance with minimal maintenance.
Key Features & Technical Specifications
- Rated Capacity: 1500 L/H (customizable for lower or higher flows)
- Wetted Material: 316L stainless steel – excellent resistance to fluorides and acidic compounds
- Control System: Siemens or Mitsubishi PLC with HMI touch screen (optional)
- Vacuum Pump: Water ring or rotary vane type, selected based on application
- Heat Source: Steam, thermal oil, or electric heating – user configurable
- Operating Vacuum: -0.08 to -0.095 MPa, maximizing evaporation efficiency
- Temperature Range: 40°C – 80°C, adjustable through PLC
- Distillate Quality: Typical COD reduction > 95%, suspended solids < 10 ppm
- Automation: Automatic start/stop, alarm, data logging, and remote access option
| Parameter | Standard Value | Notes |
|---|---|---|
| Max Evaporation Rate | 1500 L/H | Under standard conditions (30% solids feed) |
| Feed TS Concentration | Up to 35% | Depends on fluorochemical composition |
| Heating Surface Area | ~40 m² | Plate type, easy to clean |
| Power Consumption | ~45 kW (electrical + pumps) | Varies with heat source type |
| Dimensions (L×W×H) | 4000×2000×2500 mm | Approximate, customizable |
Benefits to Your Business:
- Reduce waste volume by up to 90%, lowering disposal costs significantly.
- Recover water for reuse or discharge, meeting stringent environmental standards.
- Minimize fouling – the plate design and 316L material resist scaling and corrosion.
- Save energy through vacuum operation and optional heat recovery integration.
- Simplify operation with full PLC automation – less manual intervention required.
- Extend equipment life – robust construction and quality components ensure years of service.
Frequently Asked Questions (FAQ)
-
Q: Can this evaporator handle wastewater with high fluoride content?
A: Yes, the 316L stainless steel construction provides excellent resistance to fluoride ions and acidic conditions, making it ideal for fluorochemical effluents. -
Q: What is the required feed temperature?
A: The system can operate with feed temperatures from 10°C to 50°C. Preheating is optional but recommended for higher efficiency. -
Q: Is the PLC controller user-friendly?
A: Absolutely. We use a standard HMI touch screen with intuitive menus. Training is provided, and remote support is available. -
Q: What is the typical payback period?
A: Depending on your waste volume and disposal costs, many clients achieve payback within 12–18 months. -
Q: Can the evaporator be customized for different capacities?
A: Yes, we offer models from 500 L/H to 5000 L/H. Please contact our sales team with your specific requirements. -
Q: What maintenance is required?
A: Routine inspection of vacuum pump oil, cleaning of plates every 500–1000 hours, and checking seals. Detailed manual provided. -
Q: Do you provide installation and commissioning services?
A: Yes, we offer on-site installation guidance and commissioning for overseas projects. Video support is also available. -
Q: What certifications does this product have?
A: Our manufacturing facility holds ISO9001, ISO14001, OHSAS18001, and other certifications. The evaporator can be certified as per your requirements.
As a manufacturer with an annual export value exceeding US$10 million and a team of 200+ professionals, Qingdao Conqinphi Environmental Technology Group has supplied vacuum evaporators to clients across North America, Europe, Southeast Asia, and the Middle East. Our factory spans over 10,000 square meters, equipped with advanced fabrication and testing facilities. Every unit undergoes strict quality control before shipment from Qingdao port. We back our products with comprehensive after-sales support, including spare parts supply and technical consultation. Choose our Vacuum Wastewater Plate Evaporator for a reliable, efficient, and sustainable solution to your fluorochemical wastewater challenges. Contact us today for a customized proposal!
