Heavy Duty 7th Axis Linear Rail Floor Track 2m Travel for Industrial Robot Automation
Product Spotlights
Heavy-duty floor track with 2m travel, load up to 2000kg, ±0.05mm repeatability. Universal robot interface, low maintenance, and customizable travel length. Ideal for expanding robot work envelope in welding, handling, and assembly automation by XiAn Wisdom, ISO-certified since 2015.
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
material:
High-strength steel / aluminum alloy
stroke_length:
2 meters (standard, customizable)
max_load:
Up to 2000 kg (depending on configuration)
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Industrial Spray Painting Robot Arm 6-Axis for Automated Painting LinesNegotiableMOQ: 1 Piece -
High Precision Automatic Welding Robot Multifunctional for Metal FabricationNegotiableMOQ: 1 Piece
-
User Friendly Industrial Robot Arm for Simplified Factory Automation TasksNegotiableMOQ: 1 Piece
-
High Precision 20kg Payload 6-Axis Palletizing Robot for Box and Bag PackagingNegotiableMOQ: 1 Piece
-
5-Axis Palletizing Robot 80kg Payload 2m Reach for Bagged Food HandlingNegotiableMOQ: 1 Piece
material
High-strength steel / aluminum alloy
stroke_length
2 meters (standard, customizable)
max_load
Up to 2000 kg (depending on configuration)
drive_type
Servo motor (optional)
installation
Floor-mounted
precision
Repeated positioning accuracy ±0.05 mm
applicable_robot
Any industrial robot brand (FANUC, ABB, KUKA, etc.)
certification
ISO9001, ISO14000
speed
Adjustable up to 1 m/s
XiAn Wisdom Computer Info&tech Co., Ltd presents our Heavy Duty 7th Axis Linear Rail Floor Track with a 2-meter travel, specifically designed to enhance the reach and flexibility of industrial robot automation systems. As a trusted trading company established in 2015 and serving global markets including North America, Europe, and Southeast Asia, we understand the demands of modern manufacturing. This floor track integrates seamlessly with existing robotic cells, allowing robots to move linearly along the rail, effectively expanding their working envelope without sacrificing precision or load capacity. Whether you need to automate welding, material handling, or assembly processes, our rail provides a robust and cost-effective solution.
Product Key Features
- Heavy-Duty Construction: Made from high-strength steel and reinforced aluminum, the rail withstands heavy payloads up to 2000 kg with minimal deflection.
- Precision Motion: High-precision linear guides and rack-and-pinion drive ensure repeatability of ±0.05 mm, critical for tasks like arc welding and CNC machine tending.
- Compact Design: The floor-mounted profile saves valuable floor space while offering a travel length of 2 meters (other lengths available on request).
- Universal Compatibility: Designed to work with all major robot brands; mounting interface can be customized to match your robot base.
- Low Maintenance: Sealed bearings and automatic lubrication system reduce downtime and extend service life.
- Flexible Drive Options: Available with servo motor, optional gearbox, and cable management systems for smooth integration.
Technical Specifications
| Parameter | Value |
| Travel Length | 2 meters (customizable up to 6m) |
| Maximum Payload | 1000 kg (standard) / 2000 kg (heavy-duty) |
| Repeatability | ±0.05 mm |
| Maximum Speed | 1 m/s |
| Drive Type | Servo motor (brand optional) |
| Guide System | Linear ball rail with wipers |
| Mounting | Floor anchor bolts |
| Protection Class | IP54 (optional IP65) |
Benefits for Your Automation
- Extended Robot Reach: By adding a 7th axis, one robot can service multiple workstations, reducing the need for additional robots.
- Improved Efficiency: Robots move along the rail without interrupting production flow; cycle times are optimized.
- Space Savings: Floor track installation eliminates the need for overhead gantries, ideal for plants with limited headroom.
- Cost Reduction: One robot with a linear track can replace two stationary robots, lowering capital investment and maintenance costs.
- Easy Integration: Our rail comes with pre-drilled mounting holes and wiring channels, compatible with most robot controllers via standard I/O.
Why Choose XiAn Wisdom?
Since 2015, we have built a reputation for delivering reliable industrial automation components to customers across the globe. Our team of 51–100 professionals, combined with overseas offices, ensures timely communication and support. We hold ISO9001, ISO9004, and ISO14000 certifications, reflecting our commitment to quality and environmental management. Our factory, though compact, utilizes advanced machining centers to produce rails with consistent precision. With an annual export value under US$1 million, we focus on personalized service rather than mass production, enabling quick response to custom requirements. We ship from Shanghai port, covering all major markets. Choose our Heavy Duty 7th Axis Linear Rail to boost your robot utilization—contact us today for a quotation or technical consultation.
Frequently Asked Questions
-
What is the maximum travel length available?
Standard is 2 meters, but we can customize up to 6 meters per section; longer distances can be achieved by connecting multiple sections. -
Can this rail be used with any robot brand?
Yes, it is designed to be universal. The mounting plate is adaptable to different robot base patterns. We provide adapter plates upon request. -
What maintenance is required?
Periodic lubrication of the linear guides and rack is recommended (automatic lubrication system optional). Bearings are sealed for low maintenance. -
How is the rail shipped and installed?
The rail is shipped in a single piece (if within 2m) or in sections with connection kits. Installation involves bolting to a level floor and connecting the drive motor; we provide installation manuals. -
What is the delivery time for a standard 2m rail?
Typical lead time is 15–20 working days after order confirmation, depending on current workload. -
Do you offer a warranty?
Yes, we provide a 12-month warranty against manufacturing defects. Extended warranty is optional. -
Can the rail be integrated with existing PLC or robot controller?
Absolutely. The servo drive can be controlled by the robot controller via analog/digital signals or fieldbus (Profibus, EtherCAT, etc.). -
What is the noise level during operation?
The noise level is typically below 70 dB(A) under normal load, thanks to the helical rack and sound-dampening materials.
