Welcome to Suzhou Excellence Intelligent Technology Co., LTD, a trusted trading company established in 2013, specializing in high-precision machining equipment. With a factory size of 3,000-5,000 square meters and an annual export value of US$5-10 million, we are committed to delivering reliable and efficient solutions for global customers. Our wire cut machine is engineered specifically for precision mold making and die manufacturing applications, offering exceptional accuracy, durability, and productivity. Whether you are crafting intricate injection molds or robust stamping dies, this machine ensures consistent performance to meet your most demanding requirements.
Product Overview
Our wire cut EDM machine utilizes advanced spark erosion technology to cut conductive materials with extreme precision. It is ideal for producing complex shapes, tight tolerances, and superior surface finishes required in mold and die industries. The machine features a robust construction, high-performance CNC controller, and user-friendly interface, making it suitable for both small workshops and large-scale production facilities.
Key Features & Benefits
- High Precision: Positioning accuracy of ±0.005 mm ensures flawless mold components and die inserts.
- Efficient Cutting: Maximum cutting speed up to 200 mm²/min reduces machining time and boosts productivity.
- Versatile Material Compatibility: Works with hardened steel, carbide, titanium, and other conductive alloys commonly used in tooling.
- Automatic Wire Feeding: Seamless wire threading and re-threading minimize operator intervention and downtime.
- Intuitive CNC Control: User-friendly interface with G-code support and optional CAM integration for complex profiles.
- Robust Structure: Cast iron bed and granite guideways provide thermal stability and vibration damping for long-term accuracy.
- Low Maintenance: Self-diagnostic system and easily accessible components reduce servicing costs.
- Energy Efficient: Optimized power consumption with standby mode, lowering operational expenses.
Technical Specifications
| Worktable Dimension | 800 x 600 mm (customizable up to 1200 x 800 mm) |
| Max Workpiece Weight | 800 kg |
| Wire Diameter Range | 0.15 - 0.30 mm (brass or coated) |
| Cutting Accuracy | ±0.005 mm (with compensation) |
| Surface Roughness | Ra ≤ 0.4 µm |
| Max Taper Angle | ±15° (height 80 mm) |
| Control System | Industrial PC with LCD display, optional Mitsubishi or Fanuc NC |
| Power Supply | 380V / 50Hz (customizable to 220V / 60Hz) |
| Machine Weight | 3,500 kg |
Applications in Mold & Die Making
- Injection mold cavities and cores
- Stamping dies and progressive dies
- Extrusion dies and blow mold inserts
- Precision electrode forming for EDM
- Prototype and low-volume production parts
Our wire cut machine is widely used in automotive, electronics, medical device, and consumer goods industries. It delivers repeatable results even for complex geometries, reducing the need for secondary finishing operations. With optional features like automatic wire exchanger and programmable cutting parameters, you can optimize your workflow for higher throughput.
Why Choose Suzhou Excellence Intelligent Technology?
As a dedicated trading company with over a decade of experience, we have built strong partnerships with leading manufacturers in China. Our team ensures rigorous quality control before shipment, and we offer comprehensive after-sales support including installation guidance, training, and spare parts supply. We have exported to markets across North America, South America, Europe, Southeast Asia, Africa, Oceania, and the Middle East, serving satisfied customers worldwide. Our ISO9001 certification underscores our commitment to consistent quality and customer satisfaction.
We understand that every application is unique. Our wire cut machine can be customized with additional options such as dielectric cooling system, filtration unit, or specialized software. Contact us today to discuss your specific requirements and receive a tailored quotation. Let us help you elevate your mold and die manufacturing capabilities with reliable, high-performance equipment.
Frequently Asked Questions (FAQ)
-
Q: What materials can this wire cut machine process?
A: It is designed for all conductive materials, including hardened steel, carbide, titanium alloys, copper, aluminum, and specialized tool steels used in mold making. -
Q: What is the typical delivery time?
A: Standard models typically ship within 30-45 days after order confirmation. Customized configurations may take 50-60 days. We coordinate with our logistics partners to ensure safe and timely delivery. -
Q: Does the machine come with installation and training?
A: Yes, we provide remote installation guidance and on-site training upon request (travel expenses may apply). Detailed manuals and video tutorials are also included. -
Q: What is the warranty period?
A: We offer a standard 12-month warranty covering manufacturing defects. Extended warranty plans are available for purchase. Our after-sales team responds quickly to any technical issues. -
Q: Can the machine handle 3D taper cutting?
A: Yes, with a maximum taper angle of ±15° on 80 mm height. For larger tapers, optional upgrade is available. -
Q: Is the control system compatible with common CAM software?
A: Absolutely. The CNC controller supports G-code and can import DXF, IGES, and other standard file formats. We can also recommend compatible CAM packages. -
Q: What power supply is required?
A: Standard is 380V/50Hz three-phase. We can customize for 220V/60Hz or other voltages to match your local grid. Please specify when ordering. -
Q: Do you provide spare parts?
A: Yes, we stock commonly used components such as wire guides, filters, and power boards. Consumables like brass wire and filters are also available for ongoing orders.
Ready to enhance your precision manufacturing? Contact Suzhou Excellence Intelligent Technology Co., LTD today for more details or to request a quote. Our experienced team is here to support your success.
