Help CenterPultruded FRP Rectangular Pipe, Mill Test Report Available, 2mm Thick 70x50mm, Durable
Product Spotlights
Related Products
-
Fiberglass Reinforced Round Tube, 30mm Outer Diameter, 2mm Wall, ASTM D3918, -40°C to 80°C Operating TempNegotiableMOQ: 300 Square Meters -
FRP Round Tube, 20mm ID x 3mm Wall, Pultruded Glass Fiber, Tensile Strength >300MPa, Standard CompliantNegotiableMOQ: 300 Square Meters
-
FRP Round Tube - 2 Year Warranty, Custom Cut to Length, Free Technical Support IncludedNegotiableMOQ: 300 Square Meters
-
FRP Round Tube - 100% Quality Control, Mill Test Report Provided, 30-Day Return PolicyNegotiableMOQ: 300 Square Meters
-
Glass Fiber Reinforced Plastic Round Tube, 25mm OD x 2.5mm Wall, Insulation Resistance >1GΩ, Non-ConductiveNegotiableMOQ: 300 Square Meters
Welcome to Hengshui Ruibin New Materials LLC, a professional manufacturer established in 2019 with a factory area of 1,000–3,000 square meters and an annual export value of US$2.5 Million – US$5 Million. Our team of 101–200 experienced employees is dedicated to producing high-quality composite products. We are proud to present our Pultruded FRP Rectangular Pipe (70mm x 50mm, 2mm wall thickness) — a durable, lightweight, and corrosion-resistant solution designed for demanding industrial and structural applications. Every batch comes with a Mill Test Report to guarantee consistent performance and traceability.
This product is manufactured using advanced pultrusion technology, ensuring uniform fiber orientation, precise dimensions, and excellent mechanical properties. The FRP material offers outstanding resistance to chemicals, moisture, UV radiation, and extreme temperatures, making it an ideal alternative to traditional steel, aluminum, or PVC pipes. Whether you need it for structural supports, cable trays, handrails, or chemical plant frameworks, our FRP rectangular pipe delivers long-term reliability with minimal maintenance.
Key Product Features & Benefits
- Lightweight yet strong — Density of only 1.8–2.0 g/cm³, about one-quarter the weight of steel, reducing transportation and installation costs.
- Exceptional corrosion resistance — Will not rust, rot, or degrade in harsh chemical, marine, or wastewater environments.
- Electrical insulation — Non-conductive, safe for use in electrical and telecommunication applications.
- Fire retardant option available — Customizable flame-retardant grade (upon request).
- Dimensional stability — Low thermal expansion, maintains shape under temperature fluctuations.
- UV resistance — Surface contains UV inhibitors for prolonged outdoor service life.
- Mill Test Report included — Each shipment is accompanied by a certified test report covering mechanical properties, dimensions, and material composition.
- Customizable lengths — Standard lengths up to 12 meters, or cut to your specific requirement.
Technical Specifications (Typical Values)
| Parameter | Value |
|---|---|
| Outside Dimension | 70mm x 50mm (±0.5mm) |
| Wall Thickness | 2.0mm (±0.2mm) |
| Tensile Strength | ≥ 240 MPa |
| Flexural Strength | ≥ 300 MPa |
| Compressive Strength | ≥ 200 MPa |
| Thermal Conductivity | 0.3–0.4 W/m·K |
| Service Temperature Range | -40°C to +120°C (higher with special resin) |
| Water Absorption | < 0.1% (24h immersion) |
Applications
- Structural supports & frameworks — for platforms, walkways, and equipment supports in chemical plants, water treatment facilities, and offshore structures.
- Cable trays & ladder trays — used in power stations and telecommunication rooms where electrical insulation is critical.
- Handrails & guardrails — safe, non-corrosive, and easy to install in public areas, parks, and marine environments.
- Piping & ducting — for conveying corrosive fluids, exhaust fumes, or as protective sleeves.
- Agricultural & aquaculture — greenhouse frames, fish farm structures, and irrigation supports.
- Transportation — components for truck bodies, trailers, and railway interiors where weight reduction is desired.
Our factory in Hengshui, Hebei, China operates with advanced pultrusion lines and strict quality control processes. With an annual export value of US$2.5 Million – US$5 Million, we have supplied FRP products to markets across North America, South America, Europe, Southeast Asia, Africa, Oceania, the Middle East, and more. Our 101–200 skilled workers ensure consistent quality and timely delivery. We ship from Port of Tianjin and Port of Qingdao.
We understand that every project has unique requirements. That’s why we offer customizable dimensions (other thicknesses, widths, and colors available upon request), as well as options for fire retardant, UV-stabilized, or antistatic grades. Our technical team is ready to assist with product selection and engineering support.
Mill Test Report — Your Assurance of Quality
Each order of Pultruded FRP Rectangular Pipe includes a Mill Test Report that documents mechanical properties, dimensional tolerances, and material composition. This transparency ensures you receive exactly what you specified, and it helps you meet project documentation requirements.
Choose Hengshui Ruibin New Materials LLC for your FRP needs. Our proven track record, large production capacity, and customer-centric approach make us a reliable partner for OEM, ODM, and bulk supply. Contact us today for a quote, technical datasheet, or free sample. Let us help you build stronger, lighter, and longer-lasting structures.
Frequently Asked Questions (FAQ)
1. What are the main advantages of FRP rectangular pipe compared to steel or aluminum?
FRP is much lighter (about 75% lighter than steel), completely corrosion-resistant, electrically non-conductive, and requires little maintenance. It also offers excellent strength-to-weight ratio and can be tailored with UV or fire-resistant additives.
2. Can the pipe be used outdoors in direct sunlight?
Yes, our standard FRP rectangular pipe includes UV inhibitors in the resin system to resist degradation from sunlight. For extremely harsh UV environments, a special UV-resistant coating is available upon request.
3. What is the maximum continuous service temperature?
Standard grade can be used continuously from -40°C to +120°C. If you need higher temperature resistance (up to 200°C), we can use specialized resin systems. Please advise your requirements.
4. Is the FRP pipe fire-retardant?
Standard product is not inherently fire-retardant, but we offer a fire-retardant grade that meets UL94 V-0 or similar standards. This option can be selected when ordering.
5. Can you cut the pipe to specific lengths?
Yes, we can produce any length up to 12 meters. For lengths shorter than 1 meter or custom cutting, please discuss with our sales team. Minimum order quantity may apply for custom cuts.
6. Do you provide a Mill Test Report with every shipment?
Absolutely. A Mill Test Report is included as standard for each batch. It details material composition, mechanical properties, and dimensional inspection results.
7. What is the typical lead time for this product?
For standard dimensions and quantities, lead time is usually 15–25 working days. For large orders or custom specifications, please contact us for an accurate schedule.
8. What is the minimum order quantity (MOQ)?
Our MOQ for standard size is 500 meters. However, we can accommodate smaller trial orders for first-time customers. Please inquire for details.
