Help CenterFive Axis Tool Grinder With Water Cooled Spindle 15000rpm 0.002mm Repeatability CE Compliant
Product Spotlights
Related Products
-
Five Axis CNC Tool and Cutter Grinder 8-Station Wheel Changer 60m/min Travel SpeedNegotiableMOQ: 1 Unit -
Five Axis Tool Grinder for Aerospace and Die Mold Industry Complex Profile SharpeningNegotiableMOQ: 1 Unit
-
Compact Five Axis Tool Grinder 220V Single Phase 2.2kW High Torque for Carbide ToolsNegotiableMOQ: 1 Unit
-
Five Axis CNC Tool Grinder 220V 3kW Servo Motor 0.001mm Positioning AccuracyNegotiableMOQ: 1 Unit
-
Industrial Five Axis Tool Grinder With Mill Test Report and Standard Compliant After Sales ServiceNegotiableMOQ: 1 Unit
Suzhou Excellence Intelligent Technology Co., LTD, established in 2013 with a factory size of 3,000-5,000 square meters and an annual export value of US$5 million to US$10 million, presents the Five Axis Tool Grinder with Water Cooled Spindle 15000rpm 0.002mm Repeatability. This high-precision machine is designed for efficient and accurate grinding of various cutting tools, meeting the rigorous demands of modern manufacturing. With its five-axis simultaneous motion and water-cooled spindle, it ensures superior surface finish, extended tool life, and stable performance. Our products serve diverse markets including North America, Europe, and Asia, backed by ISO9001 quality management system.
Key Technical Specifications
| Axis Configuration | 5 axes (X, Y, Z, A, C) |
| Spindle Speed | 15000 rpm (water cooled) |
| Repeatability | 0.002 mm |
| Grinding Wheel Diameter | Up to 200 mm (customizable) |
| Cooling System | Water cooled spindle & coolant through spindle |
| Control System | Siemens / Fanuc (optional) |
| Machine Weight | Approx. 3500 kg |
Product Features & Advantages
- High Precision: 0.002mm repeatability ensures consistent tool geometry, reducing scrap and rework.
- Five-Axis Flexibility: Simultaneous 5-axis motion allows grinding of complex profiles like end mills, drills, and reamers in a single setup.
- Water Cooled Spindle: Maintains stable temperature during high-speed operation (15000rpm), extending spindle life and improving grinding quality.
- User-Friendly Software: Intuitive CNC interface with tool library and automatic wheel dressing cycles.
- Robust Construction: Cast iron base and linear guideways provide vibration damping and long-term accuracy.
- CE Compliant: Meets European safety standards; optional ISO9001 certified manufacturing process.
Process Advantages
This tool grinder reduces cycle time by up to 30% compared to traditional machines, thanks to its high spindle speed and efficient five-axis interpolation. The water cooling system eliminates thermal distortion, enabling continuous heavy-duty grinding without overheating. With automatic wheel wear compensation, users achieve consistent cutting edge quality across long production runs.
Customer Benefits
- Lower tooling cost per part due to precise grinding and longer tool life.
- Reduced operator intervention with automated cycles.
- Versatile – grinds HSS, carbide, ceramics and PCD tools (with optional diamond wheels).
- Compact footprint ideal for medium-sized workshops.
Why Choose Suzhou Excellence?
With over a decade of experience and a 3,000-5,000 sqm factory, we have shipped precision tool grinders to clients across North America, Europe, Southeast Asia, and the Middle East. Our annual export value of US$5-10 million reflects the trust global customers place in our equipment. We provide comprehensive after-sales support, including on-site installation and training. The Five Axis Tool Grinder is CE compliant and manufactured under ISO9001 quality system, ensuring you receive a reliable machine that meets international standards.
Contact us today for a customized solution or a quotation. Our team is ready to assist with your specific tool grinding needs from ports like Shanghai, Ningbo, Shenzhen, and Qingdao.
Frequently Asked Questions
-
Q: What materials can this machine grind?
A: It handles carbide, high-speed steel (HSS), ceramics, and with optional diamond wheels, PCD tools. The water cooled spindle ensures stable grinding even for hard materials. -
Q: What is the delivery time?
A: Typically 30-45 days after order confirmation, depending on quantity and customization. Contact our sales for accurate lead time. -
Q: Does the machine come with training?
A: Yes, we offer on-site training and remote support. A detailed manual and video tutorials are also provided. -
Q: Can the spindle speed be adjusted?
A: The spindle speed is variable from 3000 to 15000 rpm via the CNC control. The water cooling system is effective across the range. -
Q: What warranty do you offer?
A: Standard warranty is 12 months from the date of shipment, covering manufacturing defects. Extended warranty options are available. -
Q: Is the machine compatible with common CAD/CAM software?
A: It accepts standard G-code, and we can provide post-processors for popular software like Mastercam or NX. -
Q: What is the maximum tool diameter that can be ground?
A: The maximum tool shank diameter is 25 mm, and the maximum tool length is 400 mm. Larger options are available on request. -
Q: How often does the water cooling system need maintenance?
A: We recommend checking coolant level and filter monthly. The system is designed for low maintenance with sealed components.
