As a seasoned manufacturer in the lifting equipment industry, Jiaxing Weiying Industry And Trade Co., Ltd. proudly presents this heavy-duty hydraulic floor jack specifically designed for SUVs. Our unit features two crucial enhancements: dual air bleed valves that purge gas from the hydraulic system and a manual override that allows the operator to lower the jack safely if the normal release mechanism fails. Every jack is accompanied by a mill test report, giving you documented evidence of material integrity and hydraulic performance before you put it into service.
This floor jack is the result of more than a decade of manufacturing experience, combining a solid steel chassis with a carefully tuned hydraulic unit. The result is a smooth, controlled lifting action that makes heavy SUV maintenance easier and safer. From the initial pump to the final release, the jack responds predictably, allowing you to focus on the task at hand rather than wrestling with unreliable equipment.
Key features include:
Dual air bleed valves: These valves are placed at critical points in the hydraulic circuit to automatically release trapped air. With air eliminated, the lifting piston moves steadily, and the jack avoids the dreaded spongy feeling when lowering heavy loads.
Manual override system: A mechanical override is integrated with the release valve. In the unlikely event that the hydraulic release becomes inoperable, turning the override screw manually can relieve pressure and bring the lifting arm down gently. This is a true safety net for professional operators.
High-strength steel frame: The side walls and lifting arm are constructed from thick, heat-treated steel plate, which provides exceptional resistance to bending and deformation under repeated heavy use.
Wide lifting range: The saddle can be positioned to suit the jacking points of most SUVs, pickup trucks and vans. Minimum height is low enough to slide under a flat tire, while maximum height gives ample working clearance.
Smooth rolling casters: Dual front swivel casters and rear tapered wheels allow easy positioning and support the full rated load with minimal rolling resistance.
Antifriction coating: A baked-on powder paint layer protects the external surfaces and helps resist the corrosive effect of road grime, brake fluid and workshop chemicals.
Precision hydraulic cylinder: Sealed with high-quality O-rings to prevent leakage, the cylinder is tested to ensure it holds pressure during prolonged maintenance sessions.
Test report included: A mill test report covering the chemical composition and mechanical properties of the primary steel parts is packed with each unit, providing traceability and peace of mind.
The table below gives typical specifications. Because the jack can be customized, the actual values for your order may vary slightly.
| Parameter | Typical Value / Option |
| Rated Capacity | 2T / 3T / 4T |
| Minimum Saddle Height | 85-110 mm |
| Maximum Saddle Height | 380-450 mm |
| Frame Material | Reinforced steel |
| Saddle Dimensions | 90 x 90 mm (customizable) |
| Handle Length | 1100 - 1200 mm |
| Net Weight | 25 - 35 kg |
| Air Bleed Valves | Dual |
| Manual Override | Integrated |
When lifting an SUV, it is critical that the jack has a wide footprint to prevent tipping. Our floor jack features a reinforced base plate with T-shaped ribs that maximize ground contact while keeping the weight as low as possible. The casters are positioned to remain within the footprint, providing a stable pyramid under load. Additionally, the rubber saddle pad is contoured to grip the vehicle's jacking point without damaging the metal edge.
Operating this floor jack is straightforward. The two-piece handle locks firmly into the pump socket; a 180-degree rotation opens the release valve for controlled lowering. Before lifting, the dual air bleed valves can be cracked open briefly to allow any accumulated air to escape, then closed for normal operation. This small step greatly improves the consistency of the lifting speed. For added safety, the main release valve is designed to respond instantly when you turn the handle, so you can stop the load at any point without free-fall.
The manual override feature is usually overlooked on competitive jacks, but it is indispensable for shops that follow strict safety protocols. If a seal fails and the hydraulic system becomes pressurized in an unexpected way, or if a foreign object blocks the release lever, the manual screw allows you to bleed pressure mechanically. The heat-treated scale shows the exact load position, so you always know how much stroke remains.
Routine maintenance consists of checking the hydraulic fluid level, wiping the piston shaft clean, and greasing the wheels and hinges periodically. A small maintenance kit is available upon request. We also carry a full range of replacement seals and caster kits to keep your jack operational for years. Every unit is individually load-tested before packing, and the test data is recorded in the accompanying mill test report.
Quality assurance is embedded in every production step. From incoming steel plate inspection to the final hydraulic test, our quality control team follows documented procedures. The mill test report attached to each jack contains the heat number of the steel, allowing full traceability down to the raw material supplier. This is especially valued by overseas buyers who need to comply with their own safety regulations.
As a manufacturer with a 10,000-30,000 square meter plant, 51-100 experienced workers and an annual export value of US$1 million to US$1.5 million, Jiaxing Weiying Industry And Trade Co., Ltd. has the capacity to deliver consistent quality in large volumes. Our location in Jiaxing gives us convenient access to the ports of Shanghai, Ningbo, Guangzhou and Qingdao, which allows for flexible shipping schedules to North America, South America, Eastern Europe, Southeast Asia, the Middle East and East Asia. We welcome OEM, ODM and private label projects, and we can adapt the jack to your branding and packaging requirements.
Frequently Asked Questions
Which vehicles can this hydraulic floor jack lift? The 2T/3T/4T capacity range covers most SUVs, pickup trucks, crossovers and light commercial vehicles. Always confirm the vehicle weight and choose a jack with a rated capacity above the gross vehicle weight.
Why do I need dual air bleed valves? Trapped air causes unstable lifting and a soft pedal feel. The dual valves let you evacuate air from both the pump side and the cylinder side, ensuring smooth, dependable operation.
How does the manual override operate? In normal use, the handle turns the hydraulic release valve. The manual override is a separate screw that can be rotated with a wrench to slowly relieve internal pressure even if the main valve is stuck, enabling the jack to be lowered safely.
Can the capacity, saddle height and handle length be customized? Yes, we build jacks to your specifications. You can choose the rated capacity, lifting height, saddle size and handle design, subject to a minimum order quantity.
Is the mill test report the same as a quality certificate? The mill test report is a material test certificate that documents the chemical composition and mechanical properties of the steel used. It is a strong verifiable quality indicator for B2B buyers.
What maintenance does the jack need? Maintain a correct oil level, keep the piston rod free of dirt, and lubricate moving parts every few months. If the jack becomes hard to pump, air-bleed the system using the dual valves.
Do you offer after-sales spare parts? Yes, we can supply seal kits, caster wheels, handle sets and foot pedal components. Contact us for a detailed spare parts list.
Which ports can the order be delivered from? Our usual loading ports are Shanghai, Ningbo, Guangzhou and Qingdao, and we work with reliable forwarders to arrange sea delivery worldwide.
