Product Overview
The BACCARA 1253483375 is a 2-way NC solenoid valve with a PVC main valve body and EPDM seals, designed for chemical processes, water treatment and analytical instruments. Compact and fast-responding with high control accuracy, it prevents external leakage and keeps internal leakage easily controlled. The simple system design keeps cost low while meeting heavy-duty requirements across a wide temperature range.
Key Features
2-way normally closed function
1/2" BSP port, orifice 8.0 mm, Kv 18 L/min
PVC main valve with EPDM seals for chemical media
Plastic manual override (vacuum applications)
Compact, fast response, high control accuracy
No external leakage, easy internal leakage control
Technical Specifications
Country of origin: Israel
Function: 2-way NC
Port size: 1/2" BSP
Orifice: 8.0 mm
Kv value: 18 L/min
Fluid temperature: 5 to 50 °C (non-freezing)
Ambient temperature: -10 to +50 °C
Manual override material: Plastic (vacuum applications)
Main valve material: PVC
Seal material: EPDM
Voltage tolerance: -5 to +10 % of rating
Protection class: IP65 (with connector)
Applications
Chemical processes, water treatment and analytical instruments.
