Home > Electrical & Electronics > Telecommunication & Broadcasting > WiFi Products > 4G Controller Wifi Hand Held Video Recorder Built in GPS With 2.4inch TFT for Wireless Trasmission

4G Controller Wifi Hand Held Video Recorder Built in GPS With 2.4inch TFT for Wireless Trasmission

Name: 4G Controller Wifi Hand Held Video Recorder Built in GPS With 2.4inch TFT for Wireless Trasmission
Brand: LinkAV
SKU: 100935217

4G Controller Wifi Hand Held Video Recorder Built in GPS With 2.4inch TFT for Wireless Trasmission thumbnail-1

4G Controller Wifi Hand Held Video Recorder Built in GPS With 2.4inch TFT for Wireless Trasmission thumbnail-2

4G Controller Wifi Hand Held Video Recorder Built in GPS With 2.4inch TFT for Wireless Trasmission thumbnail-3

4G Controller Wifi Hand Held Video Recorder Built in GPS With 2.4inch TFT for Wireless Trasmission thumbnail-4

4G Controller Wifi Hand Held Video Recorder Built in GPS With 2.4inch TFT for Wireless Trasmission thumbnail-5

4G Controller Wifi Hand Held Video Recorder Built in GPS With 2.4inch TFT for Wireless Trasmission thumbnail-6

4G Controller Wifi Hand Held Video Recorder Built in GPS With 2.4inch TFT for Wireless Trasmission photo-1

4G Controller Wifi Hand Held Video Recorder Built in GPS With 2.4inch TFT for Wireless Trasmission photo-2

4G Controller Wifi Hand Held Video Recorder Built in GPS With 2.4inch TFT for Wireless Trasmission photo-3

4G Controller Wifi Hand Held Video Recorder Built in GPS With 2.4inch TFT for Wireless Trasmission photo-4

4G Controller Wifi Hand Held Video Recorder Built in GPS With 2.4inch TFT for Wireless Trasmission photo-5

4G Controller Wifi Hand Held Video Recorder Built in GPS With 2.4inch TFT for Wireless Trasmission photo-6

Negotiable MOQ: 1 Pair (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

LinkAV

Model Number:

LinkAV - S2 + B

Contact Supplier Request Quote Chat Now

Shenzhen Zhongchuang Technology Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name LinkAV

Model Number LinkAV - S2 + B

Specifications

1.Use Lithium battery, long working hours> 8 hours;
2.A variety of optional 4G networks,compatible 3G,support WIFI;
3.Support dual Beidou / GPS baseband chip (option);

4.Support manual alarm function;

Features:

1. Separate design;

2. External camera can be flexibly configured;

3. Support button camera, badges cameras and others;

4. Built-in 4G, GPS, WIFI function;

5. Built-in 2.4 # TFT screen;

6. Use Lithium battery, long working hours> 8 hours;

7. Support dual Beidou / GPS baseband chip (option);

8. The latest audio and video compression technology;

9. ASF video file format standard.

10. Support 1pcs Micro-SD card, the maximum capacity can support 64G

11. IP call function (option)

12. Mobile monitoring center of platform management software (option).

Technical Parameters:

Item			Description
Separate Design			Use main and auxiliary engines separate design to flexibly meet various application scenarios
Video & Preview	Video Input		External camera
	OSD		Characters superimposed functions, time and date, device ID, GPS and other image super positions
	Video Compression Formats		H.264 compression encoding
	Dual-stream		Support
	Resolution		Default D1, CIF option
	Rate		CIF: 400 Kbps~1.5Mbps, class 4 rate is optional
			D1:1000 Kbps~2Mbps, class 4 rate is optional
	Preview Function		Real-time video preview
Audio Frequency	Audio Input		Built-in MIC
	Audio Output		Earphone output
	Compression Formats		G.726
Video	Storage Media		SD card, support 1G ~ 64G
	File Format / System		ASF/ FAT32
	Video Strategy		Default boot record, support timer recording
	Video Search		Search according to the recording date and recording type
	Video Playback		Support fast forward, fast rewind, play, pause control, support 2, 4, 8, 16 times of the speed of fast forward and fast rewind, and support the election playback control
Wireless Transmission			Built-in 4G wireless transmission module, WCDMA, CDMA2000, TD-SCDMA standard are optional; compatible with GPRS, EDGE
GPS			built-in GPS
Screen Parameter			Size: 2.4 inches; Type: TFT; Resolution: 480 * 234
System Upgrade			Support Micro-SD card upgrade
Power supply and consumption		Power Management	Manual switch, support manual off-screen, off-screen timeout automatically
		BatteryCapacity	4200mAh,7.4V
		Charging time	<3hours
		Working time	>8 hours
Work Environment		Temperature	–20°C ~ +50°C
		Humidity	20% to 95%
Size			80(W)×140(H)×35(D)mm
Net weight			475g

LinkAV-B 4G Controller

• Portable modularizeddesign, integrated 12 inch HD display, built-in lithium battery

• H.264 compression encoding,dual stream output

• Support local and long-distance PTZ control function

• Support manualalarm and capturing function

• 4G networks optional, support 3G and WIFI.

Item			Description
Operating System			Linux
Graphic User Interface			12 inch display,remote control for all system parameters
Security Administration			Two-level administration: User password, administrator password,support AES transmission
Video and Preview		Video Input, Output	Four-way video input, one-way video output ; 1.0Vp-p, 75Ω
		OSD	Characters overlay function, time and date, device ID, GPS and other image overlay
		Video Compression Formats	H.264 compression encoding, Hisilicon High Performance Processor
		Dual-stream	Support
		Preview Function	One-way, 4 divisions splicing preview, Support full screen when the event triggers and switch to display function
		FPS	PAL: 100 FPS, 25 FPS per Ch as optimum, NTSC: 120FPS, 30 FPS per Ch as optimum.
		Resolution	CIF, HD1, D1 options, can support two-way D1 and two-way CIF.
		Quality	1st to 4th grade quality evaluated, grade 1 as best, grade 4 as lowest.
		Bit Rate	CIF: 256Kbps ~ 1536Kbps,class 5 rate is optional HD1: 600Kbps ~ 2560Kbps,class 5 rate is optional D1: 800Kbps ~ 3072Kbps,class 5 rate is optional 4D1:256Kbps ~ 1536Kbps,class 5 rate is optional
Audio Frequency		Audio Input/Output	LINEIN, maximum: two-way audio input, one-way audio output: 100mV-500mV/100-500Ω
Audio Frequency		Compression Formats	G.726
Video		Storage Media	SD card, SDHC standard, support 1G ~ 64G SD card + Mobile Hard Disc;
		Storage Media	Support 2.5 inch hard disc.
		File Format / System	ASF/ FAT32
		Video Recording	Defaulted boot recording, support punctuate video recording, alarm and event trigger recording, manual recording.
		Video Search	According to time, video type or video storage equipment.
		Video Playback	Support playback, support four-way biggest synchronous playback, analyze the vehicle information in the file at the same time.
		Video Playback	Support fast forward, fast rewind, play and pause control, 2, 4, 8, 16 times fast forward or back, support playback control.
Alarm		Alarm Input/Output	Five-way level signal alarm input, two-way switch signal alarm output
		Alarm Recording	Video recording in advance,15 seconds video recording in advance before alarm, the video recording after alarm can be adjustable, about 30 seconds to 30 minutes.
		Storage Space	Alarm function for storage space left
		Business Alarm	GPS speed alarm,acceleration alarm, motion detective alarm,I/O alarm,low pressure alarm, the alarm trigger device snapshot storage.
Communication Interface		Serial Interface	Support one RS232 interface
Communication Interface		Network Interface	RJ45,10M/100M self adaptive network interface
Wireless Transmission (Optional)			Build-in 4G module,support LTE-TDD/FDD CMCC 4G,WCDMA 4G,CHA 4G optional,support 3G;built-in WiFi module;
Remote data transmission channel options			Support 4G,WIFI data channel transmission,support WIFI prior transmission strategy; Support the back-end remote download playback video strategy;
PTZ Control			Support local, client software implementation PTZ control functions;
Parameter Configuration			Support for car DVR channel coding parameters configuration function;
GPS,G-sensor,(Optional)			Support the GPS, built-in Gsensor module, geographic coordination,speed can be coded in stream
System Update			Support SD card update,long-distance update
Power supply and consumption	Power Management		1,ACC Switch 2,Delay Switch Off 3,Timer Switch
	Voltage Input		DC:+8V ~ +36V
	Voltage Output		+12V 3.5A
	Power-off Protection		UPS power endurance patented technology, with cutting off the external power supply the product is still working for 3-5 seconds, to safely save the video data when there is any unexpected power-off.
	Power		Normal working status<5W;standby mode<0.5W
Work Environment	Temperature		-25℃ ~ +70℃
Work Environment	Humidity		20% to 95%
Size/Weight			424366198mm
Size/Weight			Net Weight: 3.5Kg, Gross Weight: 6Kg
