Help CenterIP65 Compact Format Mini Metal Keyboard With 0.45mm Short Stroke
Related Products
-
MINI Type 68 Keys Compact Format Vandal Proof IP65 Stainless Steel KeyboardNegotiableMOQ: 1 Set -
IP65 Waterproof Merine Keyboard With TouchpadNegotiableMOQ: 1 Piece
-
Industrial Metal Mini 2mm Long Stroke KeyboardNegotiableMOQ: 1 Piece
-
Integrated Meta Keyboard With Trackball for KioskNegotiableMOQ: 1 Piece
-
Compact Format Vandal Proof Metal Keypad With Touch PadNegotiableMOQ: 1 Set
Special Features:
1. Industrial metal dome PCB with gold-on-gold key switch technology
2. MINI 64 keys IP65 dynmaic vandal proof stainless steel industrial keyboard,
3. With short stroke 0.45mm with excellent tactile feeling for stable and accurate data input,
4. With rear mounting solution
5. Metal keys are protected against twisting and levering which can not be dislodged from front, or defaced removing key covers.
6. Ease of customizing with multiple languages
7. Key-tops are laser-etched in legends and characters for easy readability, long life to prevent lettering rub-off.
8. PS/2, USB connection plug-and-play with PC via PC existing OS driver, no needing of install separate driver
9. Vandal-proof, against corrosion, weather-proof especially under extreme climatic conditions
Applications:
This Keyboard is mainly targeted for use for:
A: unsupervised or semi -supervised positions of varied access applications,
B: internet terminals and information kiosks at universities,
C: shopping malls, hotels, airports, railway stations and other public areas,
D: ticket vending machines, gas stations, cash machines (ATMs), Internet public phones etc.
Specifications:
MECHANICAL DATA | |
Actuator/keys |
64 keys, |
Key top style |
Non-protuberant rectangular keys, laser engraved & etched legends & raised braille on keys are available |
Key Size |
10.0mm x 10.0mm for normal keys, |
Key travel |
0.45mm |
Switch life |
more than 5 million of operations |
Actuation Force |
1.50N+/-0.1N for key 10.0mm x 10.0mm (pressure point) |
Front Plate |
1.5mm thickness super quality brushed stainless steel |
Back Plate |
3.0mm thickness brushed & oxidized aluminium |
G.W. |
1.00KGs |
Dimensions |
220.0mm x 101.0mm (front panel), 236.0mm x 109.0mm (back panel) |
ELECTRICAL DATA | |
Supply Voltage |
+5V DC +/-5% |
Current Rating |
appr. 20mA |
|
EMC Standard: |
It is compliance with the council IEC 61000-4-2:2008; |
EMI: |
EN 55022: 2010 |
EMS: |
EN 55024:2010 |
Lifespan |
> 5 years |
Switch Contact Material: |
metal dome PCB with Gold-on-Gold key switch technology |
Interface: |
PS2, USB available. |
OS: |
All windows, Linux, Unix, Mac OSX |
ENVIRONMENTAL ADAPTABILITY | |
Operating temperature |
-20oC to +60oC |
Storage temperature |
-30oC to +70oC |
Operating RH |
30-90% |
Atmospheric pressure |
60-106Kpa |
Saline mist |
96 hours, IEC 60512-6 |
Damp heat test at + 40oC |
21 days, IEC 60512-6 |
Dry heat test at + 85oC |
10 days, IEC 60512-6 |
RELIABILITY | |
Certification |
RoHS Compliant, CE and FCC, IP65, ESD |
Protection Level |
IP65(front panel) |
Vandal resistant |
IK10 |
Key Lifespan |
>10 million actuations |
MTBF |
>50000H |
MTTR |
<30min |
