Home > Industrial Equipment & Components > Valve > Ball Valve > 3 Inch Stainless Steel CF8 Dust Discharge Ball Valve DN50
3 Inch Stainless Steel CF8 Dust Discharge Ball Valve DN50
US$ 10 - 1,000
MOQ: 1 Piece
Key Specifications
Get Latest Price
Standard or Nonstandard:
Standard
Structure:
Ball
Pressure:
Medium Pressure
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Gear Operation WCB Flange Ball Valve PN16US$ 10 - 1,000MOQ: 1 Piece -
API Manual Flange End Ball Valve for Water Oil GasUS$ 10 - 1,000MOQ: 1 Piece
-
RF End Stainless Steel Ball ValveUS$ 10 - 2,000MOQ: 1 Piece
-
Board Brass Ball ValveUS$ 15 - 70MOQ: 10 Pieces
-
API WCB Stainless Steel Manual Ball ValveUS$ 10 - 1,000MOQ: 1 Piece
Standard or Nonstandard
Standard
Structure
Ball
Pressure
Medium Pressure
Power
Manual
Material
Stainless Steel
Temperature of Media
Normal Temperature
Media
Water
Port Size
ANSI B16.5
Place of Origin
Zhejiang, China
Model Number
BV105-02
Brand Name
JSV
Application
General
Product Description
Standards:
| Design & Manufacture | BS5351, GB12237 |
| Face to Face | ANSI B16.10,GB12221 |
| Flange End | ANSI B16.5,JB/T79-94 |
| Test& Inspection | API 598,GB13927 |
Technical Data:
| Nominal Pressure | 150LB | 300LB | 400LB | 600LB |
| Shell Test Pressure | 3.1 | 7.5 | 10.2 | 15.0 |
| Hydraulic Seal Test | 2.2 | 5.5 | 7.48 | 11.0 |
| Air Seal Test | 0.5~0.7 | 0.5~0.7 | 0.5~0.7 | 0.5~0.7 |
| Applicable Medium | water, oil, steam, acid | water, oil, steam, acid | water, oil, steam, acid | water, oil, steam, acid |
| Applicable Temperature | less than 200°C | less than 200°C | less than 200°C | less than 200°C |
Material Specification:
| Description | WCB | CF8 | CF3 | CF8M | CF3M |
| Body & Body Cap | A216-WCB | A315-CF8 | A35-CF3 | A351-CF8M | A351-CF3M |
| Ball | A105-1025, A216-WCB | A182-F304L, A315-CF8M | A182-F304L, A351-CF3 | A132-F316, A351-CF8M | A182-F316L, A351-CF3M |
| Stem | A182-F6a | A182-F304 | A182-F304L | A182-F316 | A182-F316L |
| Seat | RPTFE, PTFE, NYLON | RPTFE, PTFE, NYLON | RPTFE, PTFE, NYLON | RPTFE, PTFE, NYLON | RPTFE, PTFE, NYLON |
| Seat Retainer | A105-1025 | ||||
| Spring | 3yc-7, 17-49H | 3yc-7, 17-49H | 3yc-7, 17-49H | 3yc-7, 17-49H | 3yc-7, 17-49H |
| O-ring | NBR | VITON | VITON | VITON | VITON |
| Stud | A193-B7 | A193-B8 | A193-B8 | A193-B8 | A193-B8 |
| Nut | A194-2H | A194-8 | A194-8 | A194-8 | A194-8 |
Packaging & Shipping
Packing: plywood box or according to specific customer needing .
Our Services
We can produce special valves according to the requirement of clients.
Company Information
Wenzhou Jiasheng Valve Co., Ltd, is a professional valve manufacturer since 1995. Our main products include high temperature regulating metal to metal butterfly valves, rubber sealing butterfly valves, hydraulic butterfly valves, telescopic butterfly valves, ball valve, gate valve and etc. At present, we mainly produce/manufacture "ISO, API, ANSI, DIN, BS, EN, GB, JB" standard valves, also special valves according to the requirement of clients.
Workshop Situation
We have own factory :
Every product is under stringent detection and operation.
Contact
If you interested ,pls feel free to contact us .
Send Inquiry to This Supplier
Business Type
Manufacturer, Trading Company
Year Established
1995
Factory Size
1,000-3,000 square meters
Total Employees
11 - 50 People
