100mm bgs function diffuse photoelectric sensor
Feature of BGS-10 bgs function diffuse photoelectric sensor
1.Smart diffuse model and no effect by detection object angle
2.High power visible red led light, the light spot has diameter of 10mm
3.Bright indicator and A.P.R Circuit
4.Normal open and normal close can be adjustable.
5.Exclusive modulated circuit and strong anti-interference ability
Product specification
| Model | BGS-10 |
| Standard Detection Object | 1mm |
| Output Method | NPN NO NC |
| Detection Type | Diffuse |
| Detection Distance | 100mm |
| Light Source | 630nm Red modulated light |
| Operating Voltage | 12-24 VDC |
| Response Time | <0.5ms |
| Protection Degree | IP66 |
| Operating Temperature | -10℃-50℃ (No Icing) |
| Reverse Polarity Protection | Yes |
| Short Circuit Protection | Yes |
| Material | Glass fiber reinforced resin |
| Ambient Light | 500Lux incandescent light, 20000lux sunshine |
| Wire Method | diameter 3mm*2M/-4wires |
Welcome to contact me for more details.I can be reached by Skype:lynn_liu123/Wechat and Cellphone:86-13319542018
Dimension drawing
1.Prompt reply to our customer, we have to reply all the email within 24hrs
2.Provide free replacement if there is any quality problem with our product.
3. Accept OEM Order, Ship the product with your logo.
We will ship our product aboard with standard export package.
For small Qty, We will Ship our product to you by express.
For mass production , We will ship our product to you by Air or sea.
F&C Sensing Technology is a leading sensor supplier in China .Our product has been sold to all over the world.Its products cover 14 series and 3000 specification.
Our main product include Fiber Optic Sensor, Fiber optic lens, Fiber optic Lens,
Proximity Sensor, Photoelectric switch,Label Sensor, Light Curtain, Laser Alignment,
Pressure Sensor, Magnetic Switch, Connector, Laser Sensor, Color Sensor,Rail Power Supply,Solid State Relay.
F&C SensingTechnology has been making continuous breakthrough in new technologyand new application. Our target is “What you need can be found in F&C Sensing
Technology”
