Fresh Fruit Mango Juice Machine for Filling Bottles

Fresh Fruit Mango Juice Machine for Filling Bottles thumbnail-1
Fresh Fruit Mango Juice Machine for Filling Bottles thumbnail-2
Fresh Fruit Mango Juice Machine for Filling Bottles thumbnail-3
Fresh Fruit Mango Juice Machine for Filling Bottles photo-1
Fresh Fruit Mango Juice Machine for Filling Bottles photo-2
Fresh Fruit Mango Juice Machine for Filling Bottles photo-3
US$ 10,000 - 15,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Application:
Beverage, Other, Beverage, Juice Or Tea
Packaging Type:
Bottles
Contact Supplier Request Quote Chat Now
Zhangjiagang Jiazhou Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB Shanghai for mango juice machine
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Beverage, Other, Beverage, Juice Or Tea
Packaging Type Bottles
Packaging Material Plastic
Automatic Grade Automatic
Driven Type Electric
Voltage 220V
Power 2.2KW
Place of Origin Jiangsu, China
Brand Name JAIZHOU
Model Number RCGF
Dimension(L*W*H) 2500*2300*2550mm
Weight 2T
Certification CE ISO
After-sales Service Provided Engineers available to service machinery overseas

P/roduct information Zhangjiagang Jiazhou Machinery Co., Ltd.

Product description Fresh fruit mango juice machine for filling bottles
 Description:

The machine is mainly used in filling Juice, tea drink .Integrating with rinsing, filling and sealing, it has temperature control device for heat filling and realizes full automation in the whole process, suitable for polyester bottle and plastic bottle filling of juice and tea.The bottle types applicable for various parts are easily, conveniently and rapidly adjustable.It adopts new micro-negative pressure filling, stable and reliable.Compared with the machines of the same specification, the benefit of the machine is larger.
The machine adopts advanced omron programmable logic controller (plc) to control the automatic running of the machine.The input bottle adopts air conveying device;The output bottle adopts adjustable speed way, which combines with the transducer of the host machine making the output bottle running more stable and reliable.The photoelectrical inspection of the running condition of various parts makes a higher automation and convenient operation.It is the ideal first-choice equipment of beverage manufacturers.

Product display Fresh fruit mango juice machine for filling bottles

Fresh fruit mango juice machine for filling bottles



Fresh fruit mango juice machine for filling bottles



Fresh fruit mango juice machine for filling bottles

Product Parameters Fresh fruit mango juice machine for filling bottles


Model:

RCGF12-12-4

RCGF 16-16-6

RCGF 18-18-6

RCGF 24-24-8

RCGF 32-32-10

Capacity:
BPH @500ml

2000-3000

3000-5000

5000-8000

8000-12000

12000-15000

Bottle shape:

roud or square

PET bottle: (mm)

(Bottle Diameter):φ50-.φ110mm   (Height):150-340mm

Cap:

PE srew cap

Filling precision:

≤±5mm

Filling pressure:(Mpa)

0.15-0.35

Rinsing pressure:(Mpa)

0.2-0.2

Motor power: (kw)

3

3

4.5

5.5

6.5

Overall size:(mm)

1850*1600
*2350

2100*1800
*2350

2400*2150
*2350

3800*2950
*2400

3800*2800*2650

Weight: (kg)

2500

2800

3500

4500

5500

















































C/ompany information Zhangjiagang Jiazhou Machinery Co., Ltd.
Fresh fruit mango juice machine for filling bottles
O/ur advantage Zhangjiagang Jiazhou Machinery Co., Ltd.
Fresh fruit mango juice machine for filling bottles
O/ur certificate Zhangjiagang Jiazhou Machinery Co., Ltd.
Fresh fruit mango juice machine for filling bottles
N/etwork Marketing Zhangjiagang Jiazhou Machinery Co., Ltd.
Fresh fruit mango juice machine for filling bottles
P/ackaging & shipping Zhangjiagang Jiazhou Machinery Co., Ltd.
Fresh fruit mango juice machine for filling bottles
C/ontact us Zhangjiagang Jiazhou Machinery Co., Ltd.
Fresh fruit mango juice machine for filling bottles
