Product Description

Heavy vertical lathe CK5225:

1. The vertical lathe machine is for heavy metal cutting;
2. DRO is included;
3. Turning inner and outer cylindrical surfaces and planes; various curved surfaces; 4. Turning inner and outer conical surfaces; 5. Thread turning.
Double Column Vertical Lathe Machine CK5225
Specification
Unit
Maximum cutting diameter of vertical tool post
2500
mm
Diameter of worktable
2250
mm
Maximum processing height
2000
mm
Maximum weight of workpiece
20
t
Rotating speed range of worktable
2-62
r/min
Rotating speed of worktable
II step variable speed
Step
Maximum torque of worktable
63
KN/m
Feed level of tool post
Various speed
Step
Maximum cutting force of vertical tool post（left/right）
28/35
KN
Ram
Horizontal stroke
1400
mm
Vertical stroke
1000
mm
Beam stroke
1650
mm
Fast moving speed of tool post
≥2000
mm/min
Beam lifting speed
≥350
mm/min
Tool bar section size (length×width)
≥40×50
mm
Main motor power
55
kw
System Configuration
Fanuc 0i Tf
CNC axis
X.Z two-axis linkage
Machine weight (approximately)
37
t
Machine Size
5180*5200*5270
mm
Standard configuration of the machine: 1. Left turret super synchronous servo motor, program-controlled structure, with two-axis digital display; 2. Ⅱ gear stepless speed change, main servo motor; 3. Electrical Cabinet Air Conditioning Cooling.
Control System
CNC system
Fanuc 0i Tf
Number of control axes
2 axis
Number of linkage axes
2 axis
CNC axis
X 、Z
Interpolation
Straight line, arc
Compensate
With backlash, pitch error compensation, tool wear compensation and tool nose radius compensation
Coordinate setting
Workpiece coordinate setting
monitor
Color display
Magnification
Fast running rate
Controller
Built-in programmable controller
Programming
Direct drawing size programming
Feed
With manual electronic handwheel feed (hand pulse generator)
Alarm
Various alarm display for machine tool and operation
Interface
External computer interface RS-232C
Real-time profiling
Real-time display of traces
Manual feed
Hand pulse generator X, Z axis
Detailed Images
Company Profile
Customers' Feedback
FAQ
Q1: How is the warranty?
A1: Warranty time is 13 months after BL date.

Q2:Can we visit your factory before order?
A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides,we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.

Q3:Do you have a stock?
A3:Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.

Q4:What’s the MOQ?
A4:One set only.

Q5:How about your quality?
A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.

Q6:Do you have professional engineers?
A6:Yes.we have professional engineers and designers. We can provide OEM services.

Q7:Can you provide customized machines?
A7:Yes, we can design and manufacture according to your specific requirements.
