Hot Sell D280x700V Micro Mini Small Hobby Lathe Machine Price With CE
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
D180V Mini Metal Lathe Machine for Sale With CENegotiableMOQ: 1 -
D240X500 Gear Change Lathe Machine for SaleNegotiableMOQ: 1
-
GH1340W Distance 1000mm China Lathe Machine Price for SaleNegotiableMOQ: 1
-
Cheap Machine Tool GH1440W Cheap Heavy Duty Engine Lathe Machine With CENegotiableMOQ: 1
-
Mini Small Size CQ6128 DIY Hobby Lathe Machine With CENegotiableMOQ: 1
Product Description
Features:
Widely useful, operation very easy, processing scope widespread
Guaranteed concentricity precision of the main spindle less than 0.009 mm
Concentricity precision - lathe chuck smaller than 0.05 mm
Easy operating gear box has various speeds and thread cutting function
High precision and hardened spindle
Precision-manufactured, taper roller bearings in P5 quality
Powerful, maintenance-free motor
Induction-hardened and ground prismatic bed made from cast iron
Safety magnetic and lock key European-standard switch
Cost-efficient, precise and of stable value
Specification |
D280(V) |
Max. swing over bed |
φ280mm |
Distance between centers |
700mm |
Swing over cross slide |
125mm |
Width of bed |
180mm |
Spindle bore |
26mm |
Taper of spindle bore |
MT4 |
Range of spindle speeds(variable speed) |
50-2500rpm |
(6 steps) |
150 300 600 500 1000 2000rpm |
Metric threads can be cut |
0.2-4mm |
Inch threads can be cut |
8-56TPI |
Top slide travel |
70mm |
Cross slide travel |
140mm |
Tailstock quill travel |
70mm |
Taper of tailstock quill |
MT2 |
Motor power |
1500W |
NW/GW |
200/230kg |
Packing size(LXWXH) |
1450X700X680mm |
