Deqing Leixin Coating Equipment Co., Ltd. is proud to present our Automotive Powder Coating Line 50kW Curing Oven with PLC Touch Screen Control, designed for high-efficiency, consistent curing of automotive components. This advanced oven combines precise temperature control, energy-saving electric heating, and a user-friendly touch screen interface to ensure seamless operation. With a conveyor speed of 2-4 m/min, it is ideal for medium to large-scale production lines, delivering uniform coating quality and reduced cycle times. Backed by over a decade of manufacturing experience, our curing oven sets the standard for reliability and performance in the automotive powder coating industry.
Our curing oven features a robust 50kW electric heating system that provides rapid heat-up and stable temperature maintenance. The PLC touch screen control allows operators to easily program, monitor, and adjust curing parameters in real time, minimizing human error and maximizing throughput. The oven is constructed with high-grade steel and thick insulation layers to minimize heat loss, ensuring energy efficiency and a safe working environment. Below are the key technical specifications:
| Power Rating | 50kW |
| Line Speed | 2 – 4 m/min (adjustable) |
| Max Operating Temperature | 250°C (customizable) |
| Control System | PLC + HMI Touch Screen |
| Voltage | 380V/440V (3-phase, customizable) |
| Heating Type | Electric resistance heating |
Key Features & Benefits:
- High Energy Efficiency: The 50kW electric heating system is designed to minimize power consumption while maintaining precise temperature control, reducing overall operating costs.
- User-Friendly PLC Touch Screen: Intuitive interface allows operators to set curing profiles, monitor real-time data, and troubleshoot with ease. Supports recipe storage for different products.
- Uniform Heat Distribution: Advanced air circulation system ensures even temperature across the entire oven chamber, eliminating hot spots and ensuring consistent coating quality.
- Adjustable Conveyor Speed: Speed range of 2-4 m/min provides flexibility to match different production rhythms and coating thickness requirements.
- Robust Construction: Made from high-quality steel with thick rock wool insulation, the oven is durable, heat-retaining, and safe for long-term industrial use.
- Safety Features: Equipped with over-temperature protection, emergency stop, and alarm systems to safeguard both equipment and operators.
- Customizable Configuration: Oven length, temperature range, and additional options (e.g., cooling zone, filter) are available upon request to fit specific production lines.
Automotive Industry Applications: This curing oven is specifically engineered for automotive powder coating processes, including rims, engine parts, brackets, chassis components, and other metal parts that require durable, corrosion-resistant finishes. The precise control ensures that even complex geometries receive uniform coating and proper curing.
Why Choose Deqing Leixin? Since 2011, we have been a dedicated manufacturer of powder coating equipment, serving clients across North America, Europe, Asia, and beyond. With an annual export value of US$1-1.5 million and a team of 51-100 skilled employees, we have delivered hundreds of reliable coating lines worldwide. Our factory, spanning 1,000-3,000 square meters, is equipped with modern production and testing facilities. We hold ISO9001 certification, ensuring rigorous quality control from design to delivery. Our products are shipped from Ningbo and Shanghai ports, with prompt after-sales support and technical assistance.
Invest in the Automotive Powder Coating Line 50kW Curing Oven to boost your production efficiency, reduce energy costs, and achieve flawless coating results. Contact us today for a customized solution tailored to your specific requirements. Let Deqing Leixin be your trusted partner in powder coating excellence.
Frequently Asked Questions (FAQ)
-
Q: What is the maximum workpiece size the oven can handle?
A: The oven dimensions are customizable. Standard models can accommodate parts up to 1.5m width and 2m height. Please provide your part dimensions for a tailored solution. -
Q: Is the oven suitable for both powder coating and liquid paint curing?
A: Yes, with adjustable temperature control, it can be used for curing powder coatings as well as drying liquid paints. However, proper ventilation is required for liquid paint applications. -
Q: Can the PLC touch screen be integrated with an existing production line?
A: Absolutely. Our PLC system supports standard communication protocols (e.g., Modbus, Profibus) for easy integration with upstream/downstream equipment. -
Q: What is the typical lead time for this curing oven?
A: Lead time is generally 30–45 days after order confirmation, depending on customization level. We can expedite for urgent orders upon request. -
Q: Does the oven come with a cooling zone?
A: A cooling tunnel is optional and can be added after the curing oven to cool parts before unloading. Please specify when ordering. -
Q: How do you ensure uniform temperature inside the oven?
A: We use a combination of high-efficiency fans, baffles, and temperature sensors arranged in a feedback loop to maintain ±2°C uniformity across the chamber. -
Q: What certifications does the oven have?
A: Our equipment is manufactured under ISO9001 quality management system. Electrical components comply with CE standards (optional upon request). -
Q: Do you provide installation and training support?
A: Yes, we offer on-site installation guidance and remote training for the PLC control system. Detailed manuals and video tutorials are also provided.
