Qingdao Conqinphi Environmental Technology Group Co., Ltd., a leading manufacturer established in 2015 with a factory spanning 10,000–30,000 square meters and over 200 skilled employees, proudly presents the 70 TPH Triple-Effect Evaporator. This high-capacity system is designed for industries requiring efficient and reliable concentration of liquids, such as wastewater treatment, chemical processing, and food production. Every unit is delivered with a Mill Test Report and comprehensive technical training support, ensuring seamless integration into your operations. Our commitment to quality is backed by multiple certifications including ISO9001, ISO14001, and OHSAS18001, and we have exported to over 15 global markets with an annual export value of US$10–50 million.
Key Features & Technical Specifications
The 70 TPH Triple-Effect Evaporator utilizes a three-stage falling film design to maximize thermal efficiency and minimize energy consumption. Below are the core technical parameters and operational benefits:
| Parameter | Specification |
|---|---|
| Evaporation Capacity | 70 tons per hour (TPH) |
| Number of Effects | 3 (triple-effect) |
| Operating Principle | Falling film evaporation with forced circulation (optional) |
| Material of Construction | Stainless steel 304 / 316L (customizable) |
| Heat Source | Steam, hot water, or thermal fluid (customer specified) |
| Control System | PLC with HMI touchscreen, remote monitoring available |
| Included Documentation | Mill Test Report (MTR) for material traceability |
| Support | On-site technical training, installation guidance, and process optimization |
Product Advantages & Customer Benefits
- Energy Efficiency: The triple-effect design reuses vapor from the first effect as heating medium for the second, and so on, achieving up to 60% steam savings compared to single-effect evaporators.
- High Capacity: With 70 TPH throughput, this evaporator is ideal for large-scale industrial applications, reducing the number of units needed and simplifying system integration.
- Material Traceability: Every unit comes with a Mill Test Report that certifies the chemical and mechanical properties of the stainless steel used, ensuring compliance with industry standards.
- Operational Reliability: Rugged construction with corrosion-resistant materials, combined with a PLC-based control system, minimizes downtime and extends service life.
- Flexible Customization: Options include multiple material grades, heat source types, and auxiliary equipment (e.g., condensers, pumps, vacuum systems) to match your specific process requirements.
- Technical Training Support: Our team provides hands-on training for your operators and maintenance staff, covering startup, routine operation, troubleshooting, and preventive maintenance. This ensures your team can fully utilize the equipment’s capabilities from day one.
- Global Service Network: As a manufacturer with exports to North America, Europe, Asia, Africa, and Oceania, we offer timely spare parts supply and remote technical assistance.
Why Choose Qingdao Conqinphi?
Since 2015, we have grown from a small workshop to a 10,000+ m² modern factory with over 300 employees. Our annual export value of US$10–50 million reflects the trust our clients place in us. We hold multiple certifications, including ISO9001, ISO14001, OHSAS18001, HACCP, and SA8000, ensuring that every product meets rigorous quality, environmental, and social responsibility standards. Our evaporators have been deployed in diverse industries, from dairy concentration to industrial wastewater zero-liquid discharge (ZLD) projects. We invite you to experience the reliability and performance of our 70 TPH Triple-Effect Evaporator, backed by comprehensive documentation and training support. Contact us today to discuss your specific application and receive a customized proposal.
Frequently Asked Questions (FAQ)
-
Q: What is the typical payback period for this triple-effect evaporator?
A: The payback period depends on your energy costs and throughput. In many cases, the steam savings can cover the investment within 12–18 months. We can provide a detailed energy savings analysis based on your specific parameters. -
Q: Can the evaporator handle viscous or fouling liquids?
A: Yes. The falling film design is suitable for moderate viscosity, and we can incorporate forced circulation or scraped surface options for highly viscous or scaling-prone fluids. Our engineering team will evaluate your feed characteristics. -
Q: What is included in the Mill Test Report?
A: The MTR provides certified data on the chemical composition, mechanical properties (tensile strength, yield strength, elongation), and heat treatment of the stainless steel used in the evaporator. It ensures traceability to the original mill. -
Q: How long does the technical training take, and where is it conducted?
A: Typically, training lasts 3–5 days on-site at your facility. It covers installation checks, startup procedures, control system operation, routine maintenance, and emergency shutdown protocols. Remote training is also available. -
Q: What are the utility requirements for this evaporator?
A: Main utilities include steam (or hot water/thermal fluid), cooling water, and electricity for pumps and controls. A detailed utility consumption table is provided with the technical proposal. We can optimize the design to match your available utilities. -
Q: Do you offer customized material options beyond 304/316L stainless steel?
A: Yes, we can supply evaporators in Duplex stainless steel, Hastelloy, or titanium for highly corrosive environments. Please specify your process chemistry during the inquiry. -
Q: Is the evaporator CE or ASME certified?
A: We can design and manufacture to ASME, CE, or other international pressure vessel codes as requested. Our factory is equipped to comply with your local standards. Please provide your requirements during the quotation stage. -
Q: What is the lead time for this 70 TPH evaporator?
A: Typical lead time is 12–16 weeks from order confirmation, depending on customization complexity. We can expedite for urgent projects with partial penalties.
For more information, to request a quote, or to schedule a visit to our factory in Qingdao, please contact our sales team. We are committed to providing high-quality equipment and lifelong support.
