Welcome to Qingdao Conqinphi Environmental Technology Group Co., Ltd. As a professional manufacturer established in 2015, we specialize in the development and production of advanced evaporation and crystallization equipment. Our Triple-effect evaporator crystallizer with 0.5MPa steam pressure is designed to deliver high efficiency and energy savings for industrial processes. With a processing capacity of 1200L/h, this multi-stage system is ideal for concentrating and crystallizing solutions in industries such as chemical, pharmaceutical, food processing, and wastewater treatment. By leveraging triple-effect technology, we significantly reduce energy consumption while maintaining stable and reliable performance.
The triple-effect design operates at a steam pressure of 0.5MPa, allowing effective heat transfer and evaporation across multiple stages. Each stage recovers latent heat from the previous stage, leading to substantial steam savings compared to single-effect evaporators. This energy-efficient approach not only lowers operational costs but also minimizes environmental impact. The system is built from high-quality stainless steel, ensuring corrosion resistance and long service life. Customizable options are available for different materials and configurations to meet specific client requirements.
Key Features & Technical Specifications
- Triple-effect evaporation: Utilizes three stages to maximize heat recovery and minimize steam usage.
- Steam pressure: 0.5MPa (adjustable upon request) for efficient operation.
- Capacity: 1200L/h evaporation rate, suitable for medium to large-scale production.
- Energy saving: Multi-stage design reduces energy consumption by up to 50% compared to single-effect systems.
- Material: Standard stainless steel (SUS304/316L) with optional anti-corrosion coatings.
- Automation: PLC control system for precise monitoring and operation.
- Compact footprint: Space-saving design for easy integration into existing plants.
- Versatile application: Suitable for solution concentration, crystallization, and solvent recovery.
| Parameter | Value |
| Evaporation capacity | 1200 L/h |
| Steam pressure | 0.5 MPa |
| Number of effects | 3 |
| Operating temperature | Up to 150°C (depending on material) |
| Material contact parts | Stainless steel (SUS304/316L) |
| Control system | PLC + Touch screen (optional) |
| Power consumption | Low (pumps and controls only) |
Our triple-effect evaporator crystallizer is engineered to handle a wide range of feed solutions, including high-salinity wastewater, chemical by-products, and pharmaceutical intermediates. The crystallization chamber is designed to promote uniform crystal growth, resulting in high-purity solid products. The system is also equipped with automatic cleaning features to reduce downtime. With a robust construction and reliable components, this equipment is built for continuous operation in demanding industrial environments.
Why Choose Us?
Qingdao Conqinphi Environmental Technology Group Co., Ltd. is a leading manufacturer with a factory size of 10,000-30,000 square meters and over 200 employees. Our annual export value exceeds US$10 million, serving markets across North America, South America, Europe, Asia, Africa, and Oceania. We hold multiple certifications including HACCP, ISO9001, ISO14000, and OHSAS18001, ensuring our products meet international quality and safety standards. Our team offers comprehensive after-sales support, including installation guidance, commissioning, and spare parts supply. We are committed to providing cost-effective and environmentally friendly solutions to our global customers.
Contact us today to discuss your specific requirements. Our triple-effect evaporator crystallizer is customizable to match your process parameters, including steam pressure, capacity, and material of construction. We welcome inquiries and look forward to partnering with you for your evaporation and crystallization needs.
Frequently Asked Questions (FAQ)
-
What is the working principle of a triple-effect evaporator crystallizer?
The triple-effect system uses three vessels in series. Steam heats the first effect, generating vapor that is used to heat the second effect, and so on. This cascading heat recovery reduces overall steam consumption by reusing latent heat. -
Can the steam pressure be adjusted for different applications?
Yes, the steam pressure of 0.5MPa is the standard design, but we can customize the system to operate at other pressures (e.g., 0.3-0.8MPa) upon request. -
What materials are used for the construction?
The standard material is stainless steel (SUS304). For corrosive or high-purity applications, we offer SUS316L, titanium, or other alloys as options. -
How much energy does this system save compared to a single-effect evaporator?
Typically, a triple-effect evaporator reduces steam consumption by about 50-60% compared to a single-effect unit, depending on feed characteristics and operating conditions. -
What is the typical maintenance requirement?
Routine maintenance includes checking seals, cleaning heat transfer surfaces, and monitoring pressure gauges. The PLC system provides diagnostic alerts to minimize downtime. -
Is the system suitable for heat-sensitive materials?
Yes, the multi-stage design allows operation at lower temperatures in the later effects, making it suitable for heat-sensitive products such as pharmaceuticals and food extracts. -
Do you provide installation and commissioning support?
Yes, we offer remote technical guidance and on-site commissioning services. Our team can assist with integration into your existing plant layout. -
What certifications does your company hold?
Our company is certified to ISO9001, ISO14000, OHSAS18001, HACCP, and other standards. The equipment is manufactured in compliance with international quality norms.
