Help CenterCryogenic Falling Film Wastewater Plate Evaporator, 304SS, -10°C Operating Temperature for Pharmaceutical Intermediates
Product Spotlights
Related Products
-
Vacuum Wastewater Plate Evaporator, PLC Controlled, 1500L/H, 316L Stainless Steel for FluorochemicalsUS$ 8540 - 94600MOQ: 3 Combos -
Wastewater Plate Evaporator for Lithium Battery Waste Treatment, Efficient Concentration of Heavy MetalsUS$ 8540 - 94600MOQ: 3 Combos
-
Industrial Wastewater Plate Evaporator for Pharmaceutical and Pesticide Intermediates, Low Operating CostUS$ 8540 - 94600MOQ: 3 Combos
-
Automatic Wastewater Plate Evaporator, Complete Set, 380V, 5kW, for Rare Earth ExtractionUS$ 8540 - 94600MOQ: 3 Combos
-
Wastewater Plate Evaporator With 1 Year Warranty, Mill Test Report Provided, Easy MaintenanceUS$ 8540 - 94600MOQ: 3 Combos
Qingdao Conqinphi Environmental Technology Group Co., Ltd. has been a dedicated manufacturer of advanced environmental equipment since 2015. Our Cryogenic Falling Film Wastewater Plate Evaporator is engineered specifically for the demanding needs of pharmaceutical intermediates processing. With a robust 304 stainless steel construction and an operating temperature as low as -10°C, this evaporator ensures efficient concentration of heat-sensitive waste streams while maintaining product integrity. Backed by our 10,000-30,000 m² factory and experienced team of 201-300 employees, we deliver reliable solutions that meet global quality standards.
This evaporator utilizes the falling film principle on plate surfaces, maximizing heat transfer efficiency and minimizing fouling even under cryogenic conditions. Designed to handle wastewater from pharmaceutical intermediate production, it effectively separates solvents and concentrates active compounds, reducing disposal costs and enabling resource recovery. The 304SS material provides excellent corrosion resistance against organic acids and solvents commonly found in pharmaceutical effluents.
Key Product Features & Technical Specifications
- Falling Film Technology: Uniform liquid distribution across plates ensures thin film formation for rapid evaporation without thermal degradation.
- Cryogenic Operation (-10°C): Low-temperature processing preserves thermally labile pharmaceutical intermediates and reduces energy consumption compared to high-temperature evaporation.
- 304 Stainless Steel Construction: High resistance to corrosion, easy to clean, and compliant with pharmaceutical hygiene standards.
- Plate Heat Exchanger Design: Compact footprint, high heat transfer coefficient (up to 3000 W/m²·K), and easy scalability.
- Customizable Capacity: Available in multiple sizes from pilot scale (50 L/h) to industrial (10,000 L/h) to match specific production volumes.
- Integrated Vacuum System (Optional): Enhances evaporation at reduced temperatures, further protecting sensitive materials.
- Automation & Control: PLC-based control with real-time monitoring of temperature, pressure, and flow rate for consistent operation.
- Energy Efficiency: Low energy consumption per kilogram of water removed (approximately 0.8-1.2 kWh/kg), reducing operating costs.
Technical Parameters Table
| Parameter | Value |
|---|---|
| Operating Temperature | -10°C (cryogenic) |
| Material of Construction | 304 Stainless Steel |
| Heat Transfer Coefficient | 2000-3500 W/m²·K |
| Evaporation Capacity | Customizable (e.g., 500 L/h, 2000 L/h, 5000 L/h) |
| Pressure Range | Atmospheric to 0.05 MPa (gauge) |
| Power Consumption | 0.8-1.2 kWh per kg of evaporated water |
| Dimensions (L×W×H) | Varies by capacity (e.g., 2500×1200×3000 mm for 2000 L/h) |
| Weight | Approximately 1500-5000 kg depending on model |
Advantages for Your Pharmaceutical Intermediate Production
- Preserve Product Quality: Low-temperature operation prevents degradation of heat-sensitive intermediates, ensuring high purity and yield.
- Reduce Waste Disposal Costs: Concentrating wastewater reduces volume by up to 90%, lowering transportation and treatment expenses.
- Solvent Recovery: Condensed vapors can be recovered as valuable solvents, improving overall process economics.
- Compliance with Regulations: Efficiently treats pharmaceutical wastewater to meet discharge standards.
- Ease of Maintenance: Plate design allows quick disassembly and cleaning, minimizing downtime.
- Compact Footprint: Compared to traditional falling film evaporators, plate type saves floor space in your facility.
Our evaporator has been successfully deployed in multiple pharmaceutical intermediate plants across North America, Europe, and Asia. The robust 304SS construction withstands aggressive cleaning agents and corrosive effluents, while the cryogenic capability (down to -10°C) offers unmatched flexibility for heat-sensitive streams. With an annual export value exceeding US$10 million, Qingdao Conqinphi Environmental Technology Group Co., Ltd. demonstrates its commitment to delivering reliable, high-performance equipment.
Trust in Our Quality Assurance: Our factory is certified under ISO9001, ISO14000, OHSAS18001, and several other management system standards (including HACCP, TL900, SA8000, and more). With over 8 years of manufacturing experience and a dedicated R&D team, we ensure each evaporator meets stringent quality checks. We provide comprehensive after-sales support, including commissioning, training, and spare parts availability. Choose our Cryogenic Falling Film Wastewater Plate Evaporator to optimize your pharmaceutical intermediate processing while reducing environmental impact.
Ready to enhance your production? Contact us today for a customized solution. Our engineers can design a system tailored to your specific wastewater composition and capacity requirements. With shipping from Qingdao port and a global network of partners, we deliver worldwide.
Frequently Asked Questions
-
Q: What type of wastewater is suitable for this evaporator?
A: It is specifically designed for pharmaceutical intermediates wastewater containing organic solvents, acids, and heat-sensitive compounds. The 304SS material is compatible with most non-chloride environments. -
Q: Can the operating temperature be adjusted below -10°C?
A: The standard design supports -10°C. For lower temperatures, custom engineering is available upon request using specialized refrigerants and insulation. -
Q: How is the heat source supplied for cryogenic operation?
A: The evaporator typically uses a mechanical vapor recompression (MVR) system or a chilled water/glycol loop. The exact configuration depends on your site utilities and can be customized. -
Q: What cleaning and maintenance procedures are required?
A: The plate design allows easy access for manual cleaning or CIP (Clean-in-Place). We recommend periodic inspection of gaskets and seals. A maintenance manual is provided with each unit. -
Q: What capacity ranges do you offer?
A: We offer capacities from 50 L/h (pilot) up to 10,000 L/h (industrial). Intermediate sizes are customizable. Please provide your required evaporation rate for a quotation. -
Q: Do you provide installation and commissioning services?
A: Yes, we offer on-site installation supervision and commissioning by our experienced engineers. Remote support is also available for troubleshooting. -
Q: Can this evaporator be used for solvent recovery?
A: Absolutely. The condensed vapor contains valuable solvents that can be separated and reused, reducing raw material costs. A condenser and solvent collection system can be integrated. -
Q: What is the expected lifespan of the 304SS plates?
A: With proper operation and maintenance, the plates can last 10-15 years. The 304SS provides good corrosion resistance in pharmaceutical environments; for aggressive chemicals, a higher grade (e.g., 316L) is optional.
