Qingdao Conqinphi Environmental Technology Group Co., Ltd. – A trusted manufacturer since 2015, with a factory spanning 10,000–30,000 m² and an annual export value exceeding US$10 million – proudly presents our Customizable Plate and Shell Heat Exchanger, constructed from high-quality Carbon Steel. Combining the high efficiency of plate heat exchangers with the robust durability of shell-and-tube designs, this unit delivers exceptional thermal performance, lifetime technical support, and full compliance with recognized international standards. Whether you require specific dimensions, pressure ratings, or connection types, our engineering team collaborates closely with you to tailor every aspect to your exact process needs.
This heat exchanger is engineered for industries where reliability, energy savings, and compact footprint are critical. Its modular design allows easy access for cleaning and maintenance, while the carbon steel construction ensures strength and resistance under moderate corrosive conditions. With our lifetime technical support promise, you gain a dedicated partner from installation through the entire operational life, minimizing downtime and optimizing performance. Below you will find a comprehensive breakdown of its features, technical specifications, and the tangible benefits it brings to your operation.
Key Features & Benefits
- True Customizability: Heat transfer area (5–500 m²), design pressure (up to 40 bar), temperature range (−20°C to +300°C), and connection orientations can all be adapted per your project specifications.
- High Thermal Efficiency: The plate-and-shell configuration provides turbulent flow on both sides, leading to heat transfer coefficients 3–5 times higher than conventional shell-and-tube exchangers.
- Compact & Lightweight: Up to 70% smaller footprint compared to traditional designs of equal capacity – ideal for retrofits or space-constrained installations.
- Easy Maintenance: The bundled plates can be removed individually for cleaning or replacement without disturbing the shell, reducing service time and costs.
- Carbon Steel Construction: Offers excellent strength-to-weight ratio and cost-effectiveness for non-corrosive or mildly aggressive fluids; optional coatings or linings available upon request.
- Lifetime Technical Support: Our in-house engineers provide remote and on-site assistance for sizing, troubleshooting, spare parts, and performance optimization – no time limit.
- International Standards Compliance: Designed and manufactured in accordance with ASME, PED, and other recognized codes (certificates available upon request).
- Versatile Applications: Suitable for heating, cooling, condensation, or evaporation in chemical processing, oil & gas, HVAC, food & beverage, pharmaceutical, and power industries.
Technical Specifications (Typical Range – Customizable)
| Parameter | Value | Notes |
|---|---|---|
| Material | Carbon Steel (ASTM A516 Gr.70 or equivalent) | Other alloys available on request |
| Design Pressure (shell/tube side) | Up to 40 bar / up to 40 bar | Higher pressures possible with custom design |
| Design Temperature | -20°C to +300°C | Extended temperature range consult factory |
| Heat Transfer Area | 5 – 500 m² | Larger sizes available upon request |
| Plate Pattern | Herringbone / chevron, various angles | Optimized for thermal & hydraulic performance |
| Connections | Flanged (ANSI, DIN) or threaded | Orientation customizable |
| Standards Compliance | ASME VIII, PED 2014/68/EU, Chinese GB/T etc. | Certificates provided with shipment |
Customer Benefits
- Energy Savings: High heat transfer reduces utility costs – typical payback period under 18 months.
- Reduced Downtime: Simple plate access and replaceable gaskets cut maintenance hours by up to 50% compared to traditional shell-and-tube units.
- Scalable Design: Need more capacity later? Add plates to the existing shell – no need for a whole new exchanger.
- Global Logistics: Shipped from Qingdao port with efficient sea freight to North America, Europe, Asia, Oceania, Africa, and South America.
- After-Sales Confidence: Lifetime technical support includes phone, email, and video assistance, plus optional on-site service.
Our factory in Qingdao, Shandong, China, operates with a skilled workforce of 201–300 people and a comprehensive quality management system certified to ISO9001, ISO14000, OHSAS18001 and other international standards (full list available upon request). With annual exports exceeding US$10 million, we have supplied heat exchange solutions to major markets across all continents, earning a reputation for reliability and personalized service. Every unit undergoes rigorous pressure testing and dimensional inspection before delivery.
Why choose Conqinphi? Beyond the product itself, you invest in a partnership that prioritizes your process efficiency. Our engineers work closely with your team to optimize the design, provide detailed thermal calculations, and offer quick-turnaround spare parts. The lifetime technical support means you will never be left without expert guidance – a promise seldom found in this industry.
We invite you to discuss your specific heat transfer requirements with us. Submit an inquiry with your operating conditions (flow rates, temperatures, pressures, fluid properties) and we will tailor a carbon steel plate and shell heat exchanger that meets – and exceeds – your expectations. Contact our sales team today for a free preliminary sizing proposal.
Frequently Asked Questions (FAQ)
-
Q: How long does it take to customize and deliver a plate and shell heat exchanger?
A: Typical lead time for a standard custom design is 6–8 weeks after order confirmation and final drawing approval. Rush orders are possible based on factory capacity. -
Q: Can I use this heat exchanger for high-viscosity fluids or fluids with particles?
A: Yes, but the plate gap and chevron angle can be adjusted to handle moderate solids. For very high viscosity or heavy fouling, please provide fluid details so we can recommend the best plate pattern or alternative design. -
Q: What certifications or third-party inspections do you offer?
A: Our manufacturing complies with ASME VIII, PED, and Chinese GB standards. Independent inspections (e.g., Bureau Veritas, Lloyd’s) can be arranged at additional cost. Full certification documents are shipped with the unit. -
Q: Is the carbon steel suitable for seawater or chloride-containing environments?
A: Carbon steel is not recommended for seawater unless coated or lined. For chloride-rich fluids, we offer stainless steel, duplex, or titanium plate options – please consult our engineering team. -
Q: What does “lifetime technical support” actually cover?
A: It includes telephone/email troubleshooting, remote assistance via video call, replacement part identification, and advice on performance optimization. On-site service can be quoted separately if needed. -
Q: Can I replace the gaskets myself? Are spare gaskets readily available?
A: Yes, plate gaskets are designed for easy replacement. Spare gasket kits are shipped with each unit, and additional sets are always in stock for quick delivery. -
Q: What is the maximum number of plates I can add to an existing shell?
A: Each shell has a fixed rod length; our standard design allows up to a 20% increase in plate count without redesign. For larger expansions, a new shell might be required. Contact us with your initial spec for a growth plan. -
Q: Do you provide thermal design software or calculation reports?
A: Yes, we can supply detailed thermal datasheets (including pressure drop, LMTD, and UA values) upon request. For project approval, we also provide a certified calculation report.
