Cross Wedge Rolling Machine D1200

Cross Wedge Rolling Machine D1200 thumbnail-1
Cross Wedge Rolling Machine D1200 photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangxi, China
Brand Name:
Xiashi
Model Number:
D1200
Contact Supplier Request Quote Chat Now
Guangxi Xiashi Machinery Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangxi, China
Brand Name Xiashi
Model Number D1200
After-sales Service Provided Engineers available to service machinery overseas



Product Description



Features and Specifications for your reference



1.Center distance between two roller

Nominal centre distance    mm      1250

maximum distance between centers     mm      1290

2.Mould dimensions

outer diameter  mm      1200

inner diameter      mm      1000

maximum width   mm      1200

3.Dimension of roller (Diameter x Length )mm  Ø1000x1200

4.Semi-finished product

 Max.Length   mm     900

Max.diameter  mm     Φ130

section shrinkage  %       75%

The normal temperature of rolling    °C      1050-1150

The lowest temperature    °C      1000

5.Adjusting parameters of roll

 Adjustment amount of top roll       ±40mm

 Axial adjustment of bottom roll        10mm

 Phase adjustment of bottom roll       7°

6.Revolution of roller    r/min        5

7.Main motor

Model              Y355M1-6

Power   KW        160

Rotating speed        r/min   980

8.Driving system

Wheel gear lubrication        Enclosed gear oil as a lubricant

ratio of gear              120:1

9.Downsystem

Press motor            2.2KW-8(2 sets)

Rotating speed         720 r/min

pressingspeed          90mm/min





 Cross wedge rolling machine D1200Cross wedge rolling machine D1200











Cross wedge rolling machine D1200









Cross wedge rolling machine D1200















Cross wedge rolling machine D1200
