Help CenterPinch Valve VF Series
Related Products
Product specification: 40-250
Packing instructions: carton, wooden case
Stats:
Pressure range: 2-6bar
Applicable temperature: -20℃ - +150℃
Structure: sac type
Seal form: soft seal type
Body material: Aluminum alloy, stainless steel
Spool material: natural rubber, food grade natural rubber, EPDM, etc
Applicable media: powder, particle, solid liquid mixture, etc
Brand: XNFM
Model: VF
Origin: Zhejiang
Processing customization: Yes
Product Description:
Over the years, Zhejiang Xingneng has been for customers to solve the transportation and control of materials under various working conditions.
Combined with the experience accumulated in the field of bulk solid material transportation, we designed and manufactured the pinch valve, which is a new type of valve, relying on its own structural advantages, in reaching the service life, only need to replace the rubber, without any metal parts replacement, you can get a new pinch valve!
Combined with the wear resistance, corrosion resistance, high temperature resistance and other characteristics of rubber itself, we can solve the switch control and flow control of some wear and corrosive solids and liquids containing particles, powders, fibers, viscose and so on for customers.
With its unique structure and material advantages, pinch valve has a wide range of application prospects in mining metallurgy, ceramic production, plastics industry, equipment process control, petrochemical, pulp and paper industry, energy industry, water treatment, pneumatic conveying and other industries!
Zhejiang Xingneng will provide you with high-quality and affordable pinch valves to replace butterfly valves, ball valves, diaphragm valves, plug valves and other traditional valves that can not meet some harsh conditions.
