Help CenterPlate Diverter Valve KFB
Related Products
Product Specification: DN50 ~ 600(2 "~ 24")
Packing instructions: wooden cases
Stats:
Pressure range: 0~1.5bar
Applicable temperature: -20℃~250℃
Structure: plate or plunger type
Pipe Angle :30° 45° 60° 90°120 °135°
Drive mode :Manual, pneumatic
Seal form: soft seal type
Connection mode: Flange connection
Flange connection standard:ANSI B 16.5 150LB,GB,HG,SH or designed by client
Main materials: SS304, SS304L, SS316, SS316L, WCB
Applicable medium solid material (powder, granular material, powder mixture, flake, etc.)
Brand: XNFM
Model: KFB
Origin: Zhejiang Wenzhou
Processing customization: YES
Main features:
1. Polishing accuracy up to 400#, up to food grade, drug grade requirements;
2. Perfect automatic control system to ensure efficient operation reliability.
3. The shell and main parts are tightly cast, strong structure, high strength and not easy to deform, beautiful appearance.
Product Description:
The valve adopts manual or pneumatic control mode, which is widely used in chemical plastics, metallurgical minerals, energy saving and environmental protection, building materials, glass ceramics, food and beverage and other fields of powder transportation.
Brand:
Our company can design and manufacture according to the technical parameters provided by users, such as: nominal pressure, nominal diameter, pipe installation Angle, flange standard, etc. Special design: The working temperature is -20℃≈250℃. And according to the manufacturing acceptance standards and manufacturing acceptance to provide product selection, use, installation, maintenance and supporting equipment use of technical support services.
