As a leading manufacturer from Qingdao Conqinphi Environmental Technology Group Co., Ltd., we are proud to introduce our 70 TPH Triple-Effect Evaporation System, crafted from premium 304 stainless steel and equipped with advanced PLC control. This system is designed to deliver high efficiency and reliability for industrial wastewater concentration and resource recovery, helping you reduce operational costs while meeting environmental standards. With over 8 years of experience and a dedicated team of 201-300 employees, we ensure every unit meets rigorous quality benchmarks.
Our evaporation system leverages triple-effect technology to maximize energy savings, achieving up to 70% reduction in steam consumption compared to single-effect systems. The 70 TPH capacity makes it suitable for large-scale applications such as chemical, pharmaceutical, food processing, and textile industries. The 304 stainless steel construction ensures excellent corrosion resistance and longevity, even when handling aggressive feed streams. The PLC control panel allows for precise monitoring and automation, minimizing manual intervention and ensuring consistent performance.
Key Features & Technical Specifications
| Parameter | Details |
|---|---|
| Evaporation Capacity | 70 TPH (customizable from 50-100 TPH) |
| Material of Construction | 304 Stainless Steel (316L optional) |
| Number of Effects | Triple-Effect |
| Control System | PLC with HMI touchscreen, remote monitoring optional |
| Power Supply | 220V/380V, 50Hz/60Hz (other voltages available) |
| Steam Consumption | Approx. 0.35-0.45 kg steam per kg water evaporated |
| Operating Temperature | 60-100°C (adjustable) |
| Dimensions (L×W×H) | Customized per site requirements |
Product Advantages & Customer Benefits
- Energy Efficiency: Triple-effect design reduces steam consumption by up to 60% compared to single-effect systems, leading to significant operational cost savings.
- Durable Construction: 304 stainless steel provides excellent resistance to corrosion and scaling, ensuring long service life even with harsh chemical streams.
- Fully Automatic PLC Control: The PLC system automates temperature, pressure, and flow control, reducing labor requirements and human error. Real-time data logging and alarm functions enhance safety.
- Compact Footprint: Optimized layout saves floor space in your facility, while modular design allows easy expansion or integration with existing processes.
- Versatile Applications: Suitable for concentrating wastewater, brine, fruit juices, dairy products, and other heat-sensitive liquids. Customizable to meet specific feed characteristics.
- Low Maintenance: Self-cleaning CIP (Clean-in-Place) system is optional, minimizing downtime and manual cleaning efforts.
- Global Voltage Compatibility: Standard 220V/380V supply, with options for other voltages to match your local grid.
Our triple-effect evaporator is designed with a focus on sustainability. By recovering valuable water and reducing waste volume, you can lower your environmental footprint and comply with increasingly stringent discharge regulations. The system also supports zero-liquid discharge (ZLD) configurations when combined with a crystallizer, making it a future-proof investment.
Why Choose Qingdao Conqinphi Environmental Technology?
With an annual export value exceeding US$10 million and a factory spanning 10,000-30,000 square meters, we have the capacity and expertise to deliver large-scale evaporation systems to clients worldwide. Our products are exported to markets across North America, South America, Europe, Southeast Asia, Africa, and the Middle East, demonstrating our global reliability. We are ISO9001 certified, ensuring that every system undergoes stringent quality control from design to delivery.
Our team of over 200 professionals includes experienced engineers and technicians who provide comprehensive after-sales support, including installation guidance, commissioning, and training. We also offer spare parts and maintenance services to keep your system running at peak performance. Choose Conqinphi for a partner that prioritizes your success.
Contact us today to discuss your specific requirements and receive a customized quotation. Our evaporation system is ready to transform your industrial processes and deliver long-term value.
Frequently Asked Questions (FAQ)
-
Q: What is the typical payback period for this triple-effect evaporator?
A: The payback period depends on your feed volume, energy costs, and local regulations. Typically, clients see a return on investment within 12-24 months due to reduced steam consumption and water recovery. -
Q: Can the system handle feed streams with high fouling tendencies?
A: Yes, the 304 stainless steel construction resists scaling, and we offer optional automatic cleaning cycles (CIP) and anti-fouling coatings to handle challenging liquids. -
Q: Is the PLC control system compatible with remote monitoring?
A: Yes, we can integrate remote monitoring via Ethernet or SCADA for real-time data access and control from your central control room. -
Q: What certifications does your company hold for quality assurance?
A: Our company is ISO9001 certified, and we follow strict quality management procedures. Additional certifications like OHSAS18001 are also held, ensuring safety and reliability. -
Q: What is the standard lead time for a 70 TPH system?
A: Lead time is typically 45-60 days after receipt of deposit, depending on customization requirements and current production schedule. -
Q: Do you provide installation and commissioning support?
A: Absolutely. We offer on-site installation supervision, commissioning, and training for your operators. Remote support via video call is also available. -
Q: Can the system be powered by alternative energy sources like solar?
A: The system is designed to use steam as the heating medium, but we can integrate with solar thermal or waste heat recovery systems upon request. -
Q: What is the warranty period?
A: We provide a standard 12-month warranty covering manufacturing defects. Extended warranty options are available for purchase.
