Qingdao Conqinphi Environmental Technology Group Co., Ltd. has been a trusted manufacturer of advanced evaporation systems since 2015. With a factory spanning 10,000–30,000 m² and over 200 skilled employees, we specialize in delivering high-performance water treatment solutions for global industries. Our MVR ZLD Evaporator with 8000L/h Evaporation Rate is designed to achieve true zero liquid discharge while maximizing energy efficiency through mechanical vapor recompression. Equipped with a fully automatic touch screen PLC, this system simplifies operation, reduces labor costs, and ensures consistent, reliable performance even in demanding environments.
This evaporator integrates advanced MVR technology, which recycles the latent heat of vaporization, cutting energy consumption by up to 60–70% compared to traditional multi-effect evaporators. The 8000 L/h capacity makes it ideal for medium-to-large-scale wastewater treatment in industries such as chemicals, pharmaceuticals, food processing, mining, and textiles. The system is built with corrosion-resistant materials and features a compact footprint, allowing flexible installation. Below is a summary of key technical specifications:
| Parameter | Value |
|---|---|
| Evaporation Rate | 8000 L/h |
| Operating Temperature | 70–105°C (adjustable) |
| Compressor Type | Centrifugal / Roots (optional) |
| Power Consumption | ~45–60 kWh per ton of water evaporated |
| Control System | Siemens PLC + color touch screen |
| Material | SS316L / Duplex (customizable) |
| Dimensions (L×W×H) | 12m × 4m × 6m (approx., varies by configuration) |
Key Features & Benefits:
- Zero Liquid Discharge (ZLD): Recovers up to 99% of water as distillate, leaving only solid waste, meeting strict environmental regulations.
- Energy-Efficient MVR Technology: Mechanical compressor reuses vapor energy, drastically reducing operating costs.
- Fully Automatic PLC Control: Touch screen interface allows easy monitoring, parameter adjustment, and remote access. One-button start/stop reduces manual intervention.
- Robust Construction: High-grade stainless steel and anti-corrosion coatings ensure long service life even with aggressive feed streams.
- Modular Design: Scalable units available; can be integrated with pre-treatment or crystallization systems.
- Low Maintenance: Self-cleaning options and easy-access components minimize downtime.
- Wide Applicability: Handles high TDS, high COD, and complex waste streams including brine, RO concentrate, and industrial effluents.
Our factory in Qingdao, Shandong, with an annual export value of US$10–50 million, has shipped MVR evaporators to over 20 countries including North America, Europe, Southeast Asia, and Africa. We hold ISO9001, ISO14000, and OHSAS18001 certifications, reflecting our commitment to quality, environment, and safety. Each unit undergoes rigorous testing before shipment, and we provide comprehensive after-sales support including installation guidance, training, and spare parts supply.
Choosing the MVR ZLD Evaporator 8000L/h means investing in a reliable, cost-effective solution that reduces your water footprint and operational expenses. Our team is ready to customize the system to match your specific feed composition and site conditions. Contact us today for a detailed proposal or to arrange a factory visit.
Frequently Asked Questions (FAQ)
-
Q: What is the typical energy consumption of this evaporator?
A: The MVR system consumes approximately 45–60 kWh per ton of water evaporated, depending on feed temperature and composition. This is significantly lower than traditional thermal evaporators. -
Q: Can the evaporator handle highly corrosive or scaling liquids?
A: Yes, we offer optional materials like duplex stainless steel, titanium, or special coatings. The PLC can also control anti-scaling cycles and chemical dosing if needed. -
Q: What is the required feed water quality?
A: The system can process feed with TDS up to 150,000 mg/L or higher. Pre-treatment like softening or filtration is recommended for very high hardness or oil content. We provide a free evaluation of your water sample. -
Q: How long does installation take?
A: On-site installation typically takes 2–4 weeks, depending on site preparation. We provide on-site supervision and training for your operators. -
Q: Is remote monitoring available?
A: Yes, the PLC can be connected via Ethernet or 4G for remote access and real-time data logging. This is an optional feature. -
Q: What is the warranty period?
A: Standard warranty is 12 months from commissioning or 18 months from shipment, whichever comes first. Extended warranty plans are available upon request. -
Q: Can the evaporation rate be adjusted?
A: Yes, the PLC allows variable frequency drive control of the compressor, so the evaporation rate can be modulated between 50% and 100% of rated capacity. -
Q: Do you provide turnkey solutions including crystallization?
A: Absolutely. We can design a complete ZLD train including pre-treatment, MVR evaporation, and forced circulation crystallizer to produce dry solids. Please discuss your requirements with our engineers.
