Help CenterAutomatic MVR Evaporator System, 1000L/H Capacity, IP65 Control Panel
Product Spotlights
Related Products
-
MVR Evaporator for Chemical Industry, High Salt Concentration ProcessingUS$ 2250 - 8869000MOQ: 1 Combo -
MVR Evaporation System With 1-Year Warranty, Free Commissioning and TrainingUS$ 2250 - 8869000MOQ: 1 Combo
-
PLC Controlled MVR Evaporation System With 304 Stainless Steel, 220V, 50HzUS$ 2250 - 8869000MOQ: 1 Combo
-
Duplex Stainless Steel MVR Evaporator With 200㎡ Heat Exchange Area and CIP Cleaning SystemUS$ 54390 - 87900MOQ: 1 Combo
-
Vertical Duplex Stainless Steel MVR Evaporator 8000L/h Designed for High-Salt Wastewater EvaporationUS$ 54390 - 87900MOQ: 1 Combo
Welcome to Qingdao Conqinphi Environmental Technology Group Co., Ltd. – a professional manufacturer with over 8 years of experience in the environmental equipment industry, located in Qingdao, Shandong, China. Our factory covers an area of 10,000-30,000 square meters and we have an annual export value of US$10-50 million. We proudly introduce our Automatic MVR Evaporator System with 1000L/H capacity and IP65 control panel, designed for efficient and energy-saving evaporation in various industries. This system utilizes mechanical vapor recompression technology to significantly reduce operating costs while providing stable and reliable performance. It is an ideal solution for wastewater treatment, concentration, and resource recovery.
Our MVR evaporator system is built with high-quality stainless steel (304/316L) to ensure durability and corrosion resistance. The core component is a high-efficiency compressor (centrifugal or roots type, customizable) that recycles secondary steam, reducing energy consumption by up to 70-90% compared to traditional multi-effect evaporators. The system features a fully automatic PLC + HMI control, allowing for easy operation and real-time monitoring. The control panel is rated IP65, providing dust-tight and water-jet protection, suitable for harsh industrial environments.
Key Features and Benefits:
- Energy Saving: MVR technology consumes only a small amount of electrical power to drive the compressor, dramatically lowering steam and cooling water usage.
- Automatic Operation: PLC-based control with touch screen interface enables one-button start, continuous operation, and remote monitoring.
- IP65 Rated Panel: Protected against dust ingress and low-pressure water jets, ensuring reliable performance in wet or dusty conditions.
- Compact Footprint: Integrated design saves floor space and simplifies installation.
- Low Temperature Evaporation: Suitable for heat-sensitive materials; evaporation temperature can be as low as 60°C.
- Easy Maintenance: Modular components and access doors allow for quick inspection and cleaning.
- Customizable Capacity: Available in various sizes from 500L/H to 10,000L/H; 1000L/H is our standard configuration.
Technical Specifications:
| Parameter | Value |
| Evaporation Capacity | 1000 L/H (standard, adjustable) |
| Feed Concentration | Up to 30% (depending on material) |
| Compressor Type | Centrifugal or Roots (customizable) |
| Compressor Power | 45 kW (approximate, varies by application) |
| Evaporation Temperature | 60°C – 120°C (adjustable) |
| Control Panel Protection | IP65 (NEMA 4X equivalent) |
| Power Supply | 380V / 50Hz / 3Ph (other voltages available) |
| Material | SS304 / SS316L (optional) |
| Dimensions (L×W×H) | Customized based on configuration |
Why Choose Our Automatic MVR Evaporator System?
- Proven Technology: Hundreds of units installed worldwide across industries like chemical, pharmaceutical, food & beverage, and wastewater treatment.
- Advanced Control: User-friendly HMI with data logging, alarm history, and remote connectivity (optional SCADA integration).
- Energy Efficiency: Typical energy consumption of only 30-50 kWh per ton of water evaporated, far lower than conventional systems.
- Robust Construction: Heavy-duty frame, high-grade compressor, and fully welded piping ensure long service life.
Trust & Reliability
As a leading manufacturer headquartered in Qingdao, China, our company has exported to North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, the Middle East, and many other regions. We hold multiple quality management certifications including ISO9001, ISO14000, HACCP, OHSAS18001, and others, ensuring strict quality control. Our team of 201-300 employees includes experienced engineers and technicians dedicated to providing comprehensive after-sales support. With an annual export value exceeding US$10 million, we have built a strong reputation for delivering reliable and efficient environmental solutions. Contact us today for a customized proposal and experience the Conqinphi difference.
Frequently Asked Questions
-
Q: What is the typical energy saving ratio of an MVR evaporator compared to a multi-effect evaporator?
A: MVR technology typically reduces energy consumption by 70-90% because it recycles the latent heat of vaporization using a compressor, requiring only electricity for the compressor and pumps. -
Q: Can this system handle high-viscosity or scaling-prone liquids?
A: Yes, our design can be customized with features like forced circulation, scraped surface heat exchangers, or periodic cleaning cycles to handle challenging fluids. Please provide your specific material properties for a feasibility analysis. -
Q: What is the minimum and maximum evaporation temperature achievable?
A: The standard operating range is 60°C to 120°C. For heat-sensitive materials, we can design low-temperature versions operating at 40-60°C under vacuum conditions. -
Q: Is the control panel suitable for outdoor installation?
A: Yes, the control panel is rated IP65, meaning it is dust-tight and protected against low-pressure water jets. However, we recommend avoiding direct sunlight or extreme weather to prolong electronics life. -
Q: What certifications does your product have?
A: Our manufacturing facility is certified with ISO9001, ISO14000, HACCP, OHSAS18001, and others. Specific product certification (e.g., CE, ATEX) can be arranged upon request depending on the target market. -
Q: How long is the delivery time for a 1000L/H MVR system?
A: Typical lead time is 30-45 days after receipt of down payment, depending on configuration complexity and current order load. We can expedite for urgent projects upon negotiation. -
Q: Do you provide installation and commissioning service?
A: Yes, we offer on-site installation guidance and commissioning support via video call or our local agent. Optional full supervision service is available for an additional fee. -
Q: Can the system be integrated with existing plant control systems (SCADA/DCS)?
A: Absolutely. Our PLC supports Modbus RTU/TCP, Profibus, and other common protocols for integration with higher-level systems. We can also provide a dedicated communication gateway as an option.
