300 Heightened FRP Radome is an extended-height dome shell designed for 1~4GHz GNSS antennas, providing extra inner space for larger antenna modules. It is ideal for applications requiring enhanced clearance and wave path.
Made of low-dielectric fiberglass composite, it offers high wave transmittance and stable positioning signal. Mass production capability supports bulk orders with consistent quality and quick delivery.
Custom logo printing on the radome surface is available for brand promotion. Waterproof and anti-corrosion properties ensure long-term outdoor deployment. Custom dimension acceptable.
Product Details
Serial number |
Project |
Features and Specifications |
Serial number |
Project |
Features and Specifications |
Serial number |
Project |
Features and Specifications |
1 |
Name |
Type 370 radome |
8 |
Appearance |
Colored gelcoat |
15 |
Dielectric constant |
4.5-4.9 |
2 |
Specifications |
370*485 mm |
9 |
Resin |
Modified epoxy resin |
16 |
Operating frequency |
1 MHz - 4 GHz |
3 |
Housing wall thickness |
4.0 mm |
10 |
fiber |
E-glass fiber |
17 |
Transmittance (or insertion loss) |
≥90% |
4 |
Weight |
3.5 kg ± 0.2 kg |
11 |
Nomex honeycomb |
/ |
18 |
Operating temperature |
-40℃--80℃ |
5 |
Structure |
Single-layer |
12 |
Insertion part |
Copper nut 3*M5*15 |
19 |
Service life |
≥15 years |
6 |
Material |
Fiberglass |
13 |
Accessories |
/ |
20 |
Detailed dimensions |
See the drawing. |
7 |
Color |
white |
14 |
Packaging |
Thickened cardboard box |
